Fig. 5.
Download original image
Physical parameters resulting from inversion of Stokes profiles of the same snapshot as in Fig. 4. Top panels: vertical component of magnetic field Bz(x, y) at log τc = −1.5 (left) and log τc = −5 (right). Bottom panels: horizontal component of magnetic field Bh(x, y) at log τc = −1.5 (left) and log τc = −5 (right).
