Simulations of the 2:1 MMR capture and stability for two-planet systems with an inner to outer planet mass ratio q of 0.1. Blue: planets bypass resonance due to rapid migration or strong eccentricity damping. Green: stable resonance capture. Yellow: overstable resonant capture. Purple: resonance escape after temporary capture. The simulations are consistent with the analysis outlined in Figure 6a.
