Fig. 6.
Download original image
Top panel: Total (0.01 − 50 Hz) fractional rms amplitude of Swift J1727.8−1613 in the LE 2 − 10 keV (black) and HE 28 − 200 keV (green) bands. Middle panel: Fractional rms amplitudes of the Type-C (red) and Type-B (blue) QPOs in the LE 2 − 10 keV band. Bottom panel: Fractional rms amplitudes of the Type-C and Type-B QPOs in the HE 28 − 200 keV band. The gray area marks the time of the soft X-ray flare and the jet ejections reported by Wood et al. (2025). The arrows indicate an upper limit.
