Fig. 1.
Download original image
RGB images of targets VLBA ID ‘338’ (top left), ‘351’ (top right), ‘408’ (bottom left), and ‘498’ (bottom right). These were obtained by combining the F150W, F277W, and F444W JWST/NIRCam filters (Franco et al. 2025) covering a 5″ × 5″ field of view. The NIRCam pixel scale is 30 mas. The white contours are the VLA 3 GHz levels (Smolčić et al. 2017) at three, four, five, and six times the rms (2.3 μJy/beam; the VLA beam size is 0.75″ as shown by the white circle in the bottom left). In the zoomed-in images of the red panels, the purple contours are the levels at two, three, four, five, and six times the image rms detected by the VLBA, which come from a 0.2″ × 0.2″ field of view (also outlined by the red square at the centers of the galaxies). The dotted purple contour also shows the −3 rms level. The VLBA beam size for each detection is: 26 × 5 mas2 (‘338’), 26 × 5 mas2 (‘351’), 28 × 5 mas2 (‘408’), and 23 × 6 mas2 (‘498’), with a similar position angle PA ∼ 162°.
