1 Introduction

Polarisation by interstellar and circumstellar grains is currently a topic of great interest in astronomy as the arrival of new data outstrips the ability of the current models to coherently explain these data. It is clear that the use of homogeneous, single-component particles is too simplistic (e.g. Jones 2011), and it is perhaps this that most restricts our current understanding. Cosmic dust is indeed far from simple, and modelling realistic dust shapes (quasi-spherical, quasi-spheroidal, quasi-ellipsoidal, irregular, etc.) and complex structures (homogeneous, mantled, aggregate, aggregated core–mantled, etc.; e.g. Ysard et al. 2018, 2019) can be computationally expensive, especially with methods such as the discrete dipole approximation (DDA; see e.g. Draine & Flatau 2000) or T-matrix (Mishchenko et al. 1996), depending on the required volume element resolution. A full investigation therefore involves a time-consuming and computationally heavy exploration of a very diverse parameter space (wavelength, size, shape, and structure; e.g. Ysard et al. 2018, 2019; Carpine et al. 2025).

A theory, and the exact solutions, for the light scattering properties of homogeneous, isotropic, spheroidal particles was developed and evaluated about half a century ago by Asano & Yamamoto (1975) and Asano (1979), and that for the scattering and absorption properties of coated spheroids presented not long after by Onaka (1980) and van de Hulst (1981). With these methods it became possible to determine and explore the optical properties of homogeneous spheroids with size parameters π(l/λ) < 30 (e.g. Asano 1979), where l is a characterising particle dimension and λ is the wavelength of the incident radiation. Using the analytical solutions of Asano & Yamamoto (1975), Rogers & Martin (1979) investigated the extinction and polarisation produced by spheroidal particles and were able to put some constraints upon the likely shapes and refractive indices of interstellar grains by assuming a homogeneous, spheroidal dust model and good grain alignment.

Following the logic of the THEMIS model (The Heterogeneous dust Evolution Model for Interstellar Solids; Jones et al. 2013; Köhler et al. 2015; Jones et al. 2017; Ysard et al. 2024), we do not enter into the full complexity of dust but, as a small step in this direction, consider the optical and polarising properties (Q_i, i = ext, sca, and abs, including their ∥ and ⊥ components) of (hydrogenated) amorphous carbon (a-C(:H); Jones 2012a,b,c)¹ mantled spheroidal amorphous silicate (a-Sil) particles, and core–mantle (CM) carbonaceous particles, using the derived optical constants of these materials (Jones 2012a,b,c; Demyk et al. 2017a,b, 2022).

In this paper we begin by summarising and explicitly stating the equations needed to derive the optical properties of CM spheroidal particles. In this we were aided by the seminal works of van de Hulst (1981) and Bohren & Huffman (1998) and greatly in the debt of these authors. In the following we develop and extend the work of these authors to some more particular mantle shapes.

This work is organised as follows: Section 2 outlines the fundamental equations for co-axial, confocal, and constant-depth mantled spheroids, Sect. 3 gives the extinction, absorption, scattering, and polarisation cross-sections for mantled spheroids, Sect. 4 presents the results of the calculations and comparisons with numerical calculations made with DDSCAT and effective medium theory (EMT) volume-averaging methods, and Sect. 5 summarises this work and concludes.

2 The equations for mantled spheroids

We first consider the general equations for un-mantled or bare ellipsoids and spheroids but thereafter only consider spheroids. In ellipsoidal particles the three semi-major axes (a, b, and c) are unequal (a ≠ b ≠ c), and the particle shape and volume, V, are defined, with reference to the orthogonal Cartesian axes x, y, and z, by $$\frac{x^2}{a^2}+\frac{y^2}{b^2}+\frac{z^2}{c^2}=1\text{\hspace{0.17em}and\hspace{0.17em}}V=\frac{4}{3}\pi (abc),$$(1)

respectively. The determination of the surface area is considerably more complex (see later). In the simpler case of spheroidal particles with two of the semi-major axes of equal length, where a ≠ b and c = b, the shape and volume are defined by $$\begin{array}{rl}& \frac{x^2}{a^2}+\frac{1}{b^2}(y^2+z^2)=1\text{or}{x}^2+{\left(\frac{a}{b}\right)}^2(y^2+z^2)=a^2\text{and}\\ \\ & V=\frac{4}{3}\pi \left(a{b}^2\right),\end{array}$$(2)

respectively. The eccentricities for prolate (e_p, a > b) and oblate spheroids (e_o, a < b) are $$e_p={(1-\frac{b^2}{a^2})}^{\frac{1}{2}}\text{\hspace{0.17em}and\hspace{0.17em}}{e}_o={(\frac{b^2}{a^2}-1)}^{\frac{1}{2}}.$$(3)

Given that we no longer need to consider the c axis in our equations for spheroids, by convention, we use c for the linear eccentricity $c=\sqrt{}(a^2-b^2)$. The third semi-major axis is now labelled c′ when referred to in any of the following equations.

For spheroidal particles the shape-dependent factors L_i (i = 1, 2 or 3) used in the calculation of the particle polarisability sum to unity, that is, $$\sum _{i=1,2,3}{L}_i=1.$$(4)

For spherical particles (a = b = c′) the shape factors along the three orthogonal particle axes are equal, that is, $L_1=L_2=L_3=\frac{1}{3}$. For prolate spheroids (a > b and b = c′) the shape factor, L₁, factor along the a axis, the axis of symmetry, is given by $$L_1=\frac{(1-e_p^2)}{e_p^2}[-1+\frac{1}{2e_p}\log \left\{\frac{(1+e_p)}{(1-e_p)}\right\}],$$(5)

and for oblate spheroids (a < b and b = c′) the shape factor, L₁, again along the axis of symmetry, is equivalently $$L_1=\frac{(1+e_o^2)}{e_o^2}[1-\frac{1}{e_o}\mathrm{a}\mathrm{r}\mathrm{c}\tan (e_o)].$$(6)

Here the van de Hulst (1981) semi-axis conventions have been followed rather than those of Bohren & Huffman (1998). For both prolate and oblate spheroids the L₂ and L₃ factors are simply $L_2=L_3=\frac{1}{2}(1-L_1)$. For coated or mantled spheroidal particles the shape factors, L_i, have the same mathematical form for the particular type of spheroid core and mantle under consideration² but are obviously numerically different where the core and mantle do not have the same eccentricity. From here on the particle coating will be referred to as a mantle in order to avoid subscript confusion with the particle core, and these inhomogeneous structures are from here on referred to as CM particles. Following the THEMIS convention for CM particles, amorphous carbon mantles on amorphous silicate cores and on hydrogenated amorphous carbon cores are designated a-Sil/a-C and a-C:H/a-C, respectively.

The L_i factors as a function of (a/b) are shown in Fig. 1 for the co-axial, confocal, and constant-depth mantled spheroidal particle cases for a mantle depth ratio (a/d) ≃ 3, that is, for a relatively thick mantle in order to accentuate the difference between the core and total (core+mantle) factors. In the co-axial case, the ratio of the outer radius to that of the core is fixed in all directions; the L_i factors for core and mantle are therefore the same. As shown in Fig. 2 confocal mantles tend to make the particles more spherical, as do constant-depth mantles but less so than for the confocal form. Note that with increasing a/b the L₁ factors decrease while L₂ and L₃ increase. Of particular note is that, in the constant-depth and confocal mantle cases, the core and mantle L_i factors are offset, an effect that is more pronounced with the confocal form.

We next concentrated on the mantled forms of spheroidal particles, hereafter referred to as cores, with semi-axes a_c and b_c, and mantles of (non-)uniform depth, d, which do not necessarily have the same eccentricities as the core. In Fig. 2 we show the three different mantle depth cases that are considered here: (i) co-axial, with a constant mantle to core axis ratio (d_e), (ii) confocal, where the core and mantle have the same linear eccentricity (c), and (iii) constant depth, where the mantle depth, (d) normal to the surface is constant. The details of each of the three mantle forms are presented in the following subsections.

Fig. 1 Co-axial, confocal, and constant-depth mantled spheroidal particle Li factors for an a axis to mantle depth ratio a/d ≃ 3. The solid lines show the behaviour for the cores and core+mantle for the co-axial case. The short (long) dashed line show the cores+mantle Li factors for the confocal (constant-depth) case. The L1 factors decrease with increasing a/b, while those for L2 and L3 increase.

Fig. 2 Confocal (blue), constant-depth (red), and co-axial (black) coated or mantled spheroidal cores (green) shown in cross-section. The spheroid semi-axes are a, b, and c′, where the c′ axis is perpendicular to the plane of the figure. For the confocal case, the linear eccentricity $c=\sqrt{}(a^2-b^2)$. The coloured symbols indicate the foci of the elliptical cross-sections for the core and core+mantle.

2.1 Co-axial mantled spheroids

For co-axial CM spheroidal particles the ratio of core+mantle semi-axis to the core semi-axis, d_e, is fixed, that is, $$d_e=\left(\frac{a}{a_c}\right)=\left(\frac{b}{b_c}\right),$$(7)

and the mantle shape is defined by the equation $$\begin{array}{rl}& \frac{x^2}{{\left(a_c{d}_e\right)}^2}+\frac{1}{{\left(b_c{d}_e\right)}^2}(y^2+z^2)=1\text{\hspace{0.17em}or\hspace{0.17em}}\\ & x^2+\frac{{\left(a_c{d}_e\right)}^2}{{\left(b_c{d}_e\right)}^2}(y^2+z^2)={\left(a_c{d}_e\right)}^2=a^2.\end{array}$$(8)

The core, total (core + mantle), and mantle volumes, V_c, V_t, and V_m, respectively, are given by $$\begin{array}{rl}& V_c=\frac{4}{3}\pi \left(a_c{b}_c^2\right)=\frac{4}{3}\pi \frac{\left(a{b}^2\right)}{d_e^3},V_t=\frac{4}{3}\pi \left(a{b}^2\right),\text{\hspace{0.17em}and\hspace{0.17em}}\\ & V_m=(V_t-V_c)=\frac{4}{3}\pi \left(a{b}^2\right)(1-\frac{1}{d_e^3}).\end{array}$$(9)

In co-axial spheroids, where the ratio d_e is same in all directions, the mantle depth depends on the radial direction; it is thickest along the major axis (a) and thinnest along the minor b and c′ axes for prolate spheroids (see Fig. 2). The opposite is true for oblate spheroids. For co-axially mantled prolate spheroids (a > b) where the core and the mantle have the same axis ratio, that is, d_e = b_c/a_c = b/a, the eccentricity, e_p, in the L factors (L₁, L₂ = L₃) are the same for the particle core and its mantle, $$e_p^2=[1-{\left(\frac{b}{a}\right)}^2]=[1-{\left(\frac{b_c}{a_c}\right)}^2].$$(10)

For co-axially coated oblate spheroids (a < b) the eccentricity, e_o, in the L factors (L₁, L₂ = L₃) are, as for co-axially coated prolate spheroids, identical for the particle core and mantle, $$e_o^2=[{\left(\frac{b}{a}\right)}^2-1]=[{\left(\frac{b_c}{a_c}\right)}^2-1].$$(11)

2.2 Confocal mantled spheroids

For confocal spheroidal particles, where the foci of the core and mantle coincide, that is, they have the same linear eccentricities, c, the minor semi-axis lengths can be expressed as $$b_c=\sqrt{}(a_c^2-c^2)\text{\hspace{0.17em}and\hspace{0.17em}}b=\sqrt{}(a^2-c^2).$$(12)

The mantle depths along the major and minor axes, (a − a_c) and (b − b_c), respectively, are unequal as are the ratios of the core and mantle semi-axis ratios, that is, (a/a_c) ≠ (b/b_c). In this case the core shape is defined by the equation $$\begin{array}{rl}& \frac{x^2}{a_c^2}+\frac{y^2}{{(a_c-c)}^2}+\frac{z^2}{{(a_c-c)}^2}=1\text{\hspace{0.17em}or\hspace{0.17em}}\\ & x^2+\frac{a_c^2}{{(a_c-c)}^2}(y^2+z^2)=a_c^2\end{array}$$(13)

and the mantle shape by $$\begin{array}{rl}& \frac{x^2}{a^2}+\frac{y^2}{(a-c{)}^2}+\frac{z^2}{(a-c{)}^2}=1\text{\hspace{0.17em}or\hspace{0.17em}}\\ & x^2+\frac{a^2}{(a-c{)}^2}(y^2+z^2)=a^2.\end{array}$$(14)

The core, total, and mantle volumes, V_c, V_t, and V_m, respectively, are given by $$\begin{array}{rl}& V_c=\frac{4}{3}\pi \left(a_c{b}_c^2\right)=\frac{4}{3}\pi \left[a_c(a_c^2-c^2)\right],\\ & V_t=\frac{4}{3}\pi \left[a(a^2-c^2)\right],\text{\hspace{0.17em}and\hspace{0.17em}}\\ & V_m=(V_t-V_c)=\frac{4}{3}\pi [a^3-c^2(a-a_c)-a_c^3].\end{array}$$(15)

The linear eccentricity, c, is real for a_c ⩾ b_c and a ⩾ b, and consequently Eq. (12) is therefore strictly only valid for prolate spheroids. However, given that c² is negative for oblate spheroids and always a subtractive term in Eqs. (13)–(15), Eq. (15) does yield valid volumes for all mantled spheroidal grains³. In such spheroids the mantle depth depends on the radial direction; it is thicker along the minor axes in the case of prolate spheroids (see Fig. 2). For oblate spheroids the mantle is thicker along the major axis. For confocally mantled prolate spheroids the mantle and core eccentricities, e_p,m and e_p,c, are $$\begin{array}{rl}& e_{p,m}^2=[1-\left(\frac{a^2-c^2}{a^2}\right)]={\left(\frac{c}{a}\right)}^2\text{\hspace{0.17em}and\hspace{0.17em}}\\ & e_{p,c}^2=[1-\left(\frac{a_c^2-c^2}{a_c^2}\right)]={\left(\frac{c}{a_c}\right)}^2.\end{array}$$(16)

In the case of confocally mantled oblate spheroids the eccentricities for the entire particle and the core, e_o,m and e_o,c, are $$\begin{array}{rl}& e_{o,m}^2=[\left(\frac{a^2-c^2}{a^2}\right)-1]=-{\left(\frac{c}{a}\right)}^2\text{\hspace{0.17em}and\hspace{0.17em}}\\ & e_{o,c}^2=[\left(\frac{a_c^2-c^2}{a_c^2}\right)-1]=-{\left(\frac{c}{a_c}\right)}^2.\end{array}$$(17)

Again, the negative values do not pose a problem because c² is negative for oblate spheroids.

2.3 Constant-depth mantled spheroids

In the interstellar medium, the physical processes of accretion (of gas-phase species or nanoparticles), photo-processing in an isotropic radiation field, and erosion by sputtering all result in the formation or erosion of constant-depth surface layers. Thus, constant-depth mantles would appear to be the most appropriate case for the astrophysical situation. It is, however, also the most complex of the three. This is because in constant-depth coated CM particles, either the core or the mantle is spheroidal while the other, although it may be extremely close to exhibiting a spheroidal surface in the thin-mantle limit, is not exactly spheroidal. Thus, for coated spheroidal particles where the mantle depth, d, is constant there exist two possible cases and for both $$d=(a-a_c)=(b-b_c)$$(18)

because this expression includes only the core semi-axes and the mantle depth along those semi-axes, it says nothing of the intermediate behaviours. The two possible cases are subtly rather different because either a and b or a_c and b_c define a spheroid. Given the need to directly compare the three CM cases, and that the mantle is generally thin compared to the core size, as in the large grains in the THEMIS model (viz., 5–20 nm-thick mantles on 130–150 nm radius cores), only the spheroidal core case is considered here. The core is then taken to have an exact spheroidal form with its shape and volume, V_c, determined by the following equations: $$\begin{array}{rl}& \frac{x^2}{a_c^2}+\frac{1}{b_c^2}(y^2+z^2)=1\text{\hspace{0.17em}or\hspace{0.17em}}\\ & x^2+\frac{a_c^2}{b_c^2}(y^2+z^2)=a_c^2,V_c=\frac{4}{3}\pi \left(a_c{b}_c^2\right).\end{array}$$(19)

This is where, as referred to above, things get interesting. The mantle volume can be exactly determined using Steiner’s formula⁴ for the volume of a coating on any convex shape where the mantle depth, normal to the core surface, is the same at each point on that surface, and is given by $$V_{\text{coat\hspace{0.17em}}}=S_{c}d+\pi l{d}^2+\frac{4}{3}\pi d^3,$$(20)

where S_c is the spheroidal core surface area, l is the mean length and d is the mantle depth. The first term provides the thin mantle limit (d ≪ a_c, i.e. volume = area × depth) and the third term is the thick mantle limit (d ≫ a_c, i.e. for a spherical particle). The second term is returned to below after we consider the surface area calculation for a spheroid. The surface areas of prolate and oblate spheroidal cores, S_c,p and S_c,o, respectively, are given by $$\begin{array}{rl}& S_{c,p}=2\pi b_c^2(1+\frac{a_c}{b_c{e}_p}\mathrm{a}\mathrm{r}\mathrm{c}\mathrm{s}\mathrm{i}\mathrm{n}{e}_p)\text{and}\\ & S_{c,o}=2\pi b_c^2+\pi \frac{a_c^2}{{ϵ}_o}\log \left(\frac{1+{ϵ}_o}{1-{ϵ}_o}\right)\text{where}{ϵ}_o^2=1-\frac{a_c^2}{b_c^2}.\end{array}$$(21)

For consistency with the above-defined eccentricity, e_o, where ϵ_o = (a_c/b_c) e_o, the equation for S_c,o can be re-written as $$S_{c,o}=2\pi b_c^2+\pi \frac{a_c{b}_c}{e_o}\log \left[\frac{\left(b_c/a_c\right)+e_o}{\left(b_c/a_c\right)-e_o}\right].$$(22)

Returning to the second term in Eq. (20), this is indeed more complex but, geometrically, the mean length, l, in Eq. (20) is a mean curvature (an inverse length) times a surface area. For a spheroid (a_c ⩾ b_c ⩾ $c_c^{\mathrm{\prime }}$) this can be calculated using the following equation (see the links in the following related footnotes): $$\begin{array}{rl}l(a_c,b_c,c_c^{\mathrm{\prime }})=& \frac{1}{2\pi }{\int }_0^{2\pi }{\int }_0^{\pi }\sin \theta \sqrt{}([a_c^2{\cos }^2\varphi +b_c^2{\sin }^2\varphi ]{\sin }^2\dots \\ & \dots +{\left(c_c^{\mathrm{\prime }}\right)}^2{\cos }^2\theta )d\theta d\varphi ,\end{array}$$(23)

which can be solved numerically. Hence, in the results presented here the mantle volume was calculated using a lightly modified version of the coating.f90 code made public by F.X. Timmes⁵. Alternatively, using Thomsen’s formula, the ellipsoid surface area, S_ell, can be approximated to within ≈1% by $$S_{\mathrm{e}\mathrm{l}\mathrm{l}}=2\pi {(a_c^p{b}_c^p+a_c^p{c}_c^p+b_c^p{\left(c_c^{\mathrm{\prime }}\right)}^p)}^{1/p},$$(24)

where setting p = 1.6075 leads to a relative error of less than 1.42% (Thomsen 2004; see footnote 6) or with p = 8/5 to a maximum error of −1.178% (Cantrell 2004: see footnote 6)⁶. The particle core, mantle and total (core + mantle) volumes, V_c, V_m and V_t, respectively, are then $$V_c=\frac{4}{3}\pi \left(a_c{b}_c^2\right),V_m=V_{\text{coat\hspace{0.17em}}},\text{\hspace{0.17em}and\hspace{0.17em}}{V}_t=V_c+V_{\text{coat}}.$$(25)

For constant mantle depth, d, coated prolate spheroids, the mantle and core eccentricities, e_p,m and e_p,c, are $$e_{p,m}^2=[1-{\left(\frac{b_c+d}{a_c+d}\right)}^2]\text{\hspace{0.17em}and\hspace{0.17em}}{e}_{p,c}^2=[1-{\left(\frac{b_c}{a_c}\right)}^2].$$(26)

In the case of constant-depth coated oblate spheroids, the eccentricities for the mantle and core, e_o,m and e_o,c, are $$e_{o,m}^2=\{{\left[\frac{(b_c+d)}{(a_c+d)}\right]}^2-1\}\text{\hspace{0.17em}and\hspace{0.17em}}{e}_{o,c}^2=[{\left(\frac{b_c}{a_c}\right)}^2-1].$$(27)

2.4 Mantle volume normalisation

A comparison of the different mantle cases was made using equal volume mantles, as defined by the mantle volume in the constant-depth mantle case, the most mathematically demanding of the three scenarios. Hence, the mantle depth, d, is first defined and the mantle material volume, V_m, calculated as described above (Sect. 2.3). This volume is then used to determine the co-axial case mantle semi-axis ratio, d_e (Sect. 2.1), $$d_e={(\frac{3}{4\pi }\frac{V_m}{a_c{b}_c^2}+1)}^{\frac{1}{3}}={\left(\frac{V_t}{V_m}\right)}^{\frac{1}{3}},$$(28)

which is then in turn used to determine the core and mantle linear eccentricities, c, in the confocal CM case (Sect. 2.2) as a function of the as yet to be determined confocal case mantle semi-axis ratio, d_ec, where $$c=\sqrt{}(a_c^2-b_c^2),a=a_c{d}_{ec},\text{\hspace{0.17em}and\hspace{0.17em}}b=\sqrt{}(a^2-c^2)=\sqrt{}(a_c^2{d}_{ec}^2-c^2).$$(29)

Given that the mantle volume in the confocal case can be expressed as $$V_m=\frac{4}{3}\pi (a_c^3{d}_{ec}^3-a_c{c}^2{d}_{ec}+a_c{c}^2-a_c^3),$$(30)

finding d_ec requires solving a cubic equation of the form $d_{ec}^3+p{d}_{ec}+q=0$, that is, $$\begin{array}{rl}& 0=d_{ec}^3-{\left(\frac{c}{a_c}\right)}^2{d}_{ec}+[{\left(\frac{c}{a_c}\right)}^2-\frac{3V_m}{4\pi a_c^3}-1],\\ & \text{\hspace{0.17em}with\hspace{0.17em}}p=-{\left(\frac{c}{a_c}\right)}^2\text{\hspace{0.17em}and\hspace{0.17em}}q=[{\left(\frac{c}{a_c}\right)}^2-\frac{3V_m}{4\pi a_c^3}-1].\end{array}$$(31)

Using Cardano’s formula, this cubic equation has a real solution: $$d_{ec}=C-\frac{p}{3C}\text{\hspace{0.17em}where\hspace{0.17em}}C={[-\frac{q}{2}+{(\frac{q^2}{4}+\frac{p^3}{27})}^{\frac{1}{2}}]}^{\frac{1}{3}}.$$(32)

3 The extinction, absorption, and scattering cross-sections and polarisation of mantled spheroids

For a coated spheroidal particle, with core material dielectric function ε_c and mantle material dielectric function ε_m, embedded in a medium with dielectric function ε_v (for vacuum ε_v = 1) the polarisability of the particle as given by Bohren & Huffman (1998) is $$\begin{array}{rl}{\alpha }_i=& \frac{\left(V_t/4\pi \right)\{({\epsilon }_m-{\epsilon }_v)[{\epsilon }_m+({\epsilon }_c-{\epsilon }_m)(L_{c,i}-\left(V_c/V_t\right)L_{m,i})]}{[{\epsilon }_m+({\epsilon }_c-{\epsilon }_m)(L_{c,i}-\left(V_c/V_t\right)L_{m,i})][{\epsilon }_v+({\epsilon }_m-{\epsilon }_v)L_{m,i}]}\dots \\ \\ & \dots \frac{+\left(V_c/V_t\right){\epsilon }_m({\epsilon }_c-{\epsilon }_m)\}}{+\left(V_c/V_t\right)L_{m,i}({\epsilon }_c-{\epsilon }_m)},\end{array}$$(33)

where i = 1, 2, or 3, and α₂ = α₃. When the core and mantle are of the same material, ε_c = ε_m = ε, this reduces to $${\alpha }_i=\frac{\left(V_t/4\pi \right)(\epsilon -{\epsilon }_v)\epsilon }{\epsilon [{\epsilon }_v+(\epsilon -{\epsilon }_v)L_i]}=\left(V_t/4\pi \right){[L_i+{\epsilon }_v{(\epsilon -{\epsilon }_v)}^{-1}]}^{-1},$$(34)

the equation for an homogeneous spheroid. For each of the semi-major axes of a spheroid, i = 1, 2, and 3, with 1 parallel to the axis of symmetry and 2 and 3 perpendicular to that axis and therefore equal, the absorption and scattering efficiency factors, with absorption generally dominating over scattering at long wavelengths, are given by $$\begin{array}{rl}& Q_{\mathrm{a}\mathrm{b}\mathrm{s},\mathrm{i}}=-4x\mathrm{Im}\left({\alpha }_i\right)\text{\hspace{0.17em}and\hspace{0.17em}}{Q}_{\mathrm{s}\mathrm{c}\mathrm{a},\mathrm{i}}=\frac{8}{3}{x}^4\mathrm{a}\mathrm{b}\mathrm{s}\left({\alpha }_i^2\right),\\ & \text{\hspace{0.17em}where\hspace{0.17em}}x=\frac{2\pi }{\lambda }\frac{(a+2b)}{3}.\end{array}$$(35)

The absorption cross-sections, with respect to the particle symmetry axis, in the parallel (∥) and perpendicular (⊥) directions are then $${\sigma }_{\mathrm{a}\mathrm{b}\mathrm{s},\parallel }=\pi b^2{Q}_{\mathrm{a}\mathrm{b}\mathrm{s},1}\text{\hspace{0.17em}and\hspace{0.17em}}{\sigma }_{\mathrm{a}\mathrm{b}\mathrm{s},\perp }=\pi (ab)Q_{\mathrm{a}\mathrm{b}\mathrm{s},2}=\pi (ab)Q_{\mathrm{a}\mathrm{b}\mathrm{s},3}.$$(36)

Note that in each case the relevant cross-section is the cross-section projected along that axis. Similarly, the respective scattering cross-sections in the ∥ and ⊥ directions are $$\begin{array}{rl}& {\sigma }_{\mathrm{s}\mathrm{c}\mathrm{a},\parallel }=\pi b^2{Q}_{\mathrm{s}\mathrm{c}\mathrm{a},1}\text{\hspace{0.17em}and\hspace{0.17em}}\\ \\ & {\sigma }_{\mathrm{s}\mathrm{c}\mathrm{a},\perp }=\pi (ab)Q_{\mathrm{s}\mathrm{c}\mathrm{a},2}=\pi (ab)Q_{\mathrm{s}\mathrm{c}\mathrm{a},3},\end{array}$$(37)

and the extinction cross-sections in the ∥ and ⊥ directions are $$\begin{array}{rl}& {\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }=\pi b^2(Q_{\mathrm{a}\mathrm{b}\mathrm{s},1}+Q_{\mathrm{s}\mathrm{c}\mathrm{a},1})\text{\hspace{0.17em}and\hspace{0.17em}}\\ \\ & {\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t},1}=\pi (ab)(Q_{\mathrm{a}\mathrm{b}\mathrm{s},2}+Q_{\mathrm{s}\mathrm{c}\mathrm{a},2})=\pi (ab)(Q_{\mathrm{a}\mathrm{b}\mathrm{s},3}+Q_{\mathrm{s}\mathrm{c}\mathrm{a},3}).\end{array}$$(38)

The parallel and perpendicular absorption and scattering efficiency factors, for the three mantle shapes are compared in Fig. 3. The equally weighted, semi-major axis-averaged absorption, scattering and extinction cross-sections can be expressed as $$\begin{array}{rl}& ⟨{\sigma }_{\mathrm{a}\mathrm{b}\mathrm{s}}⟩=\frac{1}{3}({\sigma }_{\mathrm{a}\mathrm{b}\mathrm{s},\parallel }+2{\sigma }_{\mathrm{a}\mathrm{b}\mathrm{s},\perp }),⟨{\sigma }_{\mathrm{s}\mathrm{c}\mathrm{a}}⟩=\frac{1}{3}({\sigma }_{\mathrm{s}\mathrm{c}\mathrm{a},\parallel }+2{\sigma }_{\mathrm{s}\mathrm{c}\mathrm{a},\perp }),\\ \\ & \text{\hspace{0.17em}and\hspace{0.17em}}⟨{\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t}}⟩=⟨{\sigma }_{\mathrm{a}\mathrm{b}\mathrm{s}}⟩+⟨{\sigma }_{\mathrm{s}\mathrm{c}\mathrm{a}}⟩\text{.\hspace{0.17em}}\end{array}$$(39)

3.1 Polarisation by mantled spheroids

We next considered the polarisation properties of mantled spheroids. Given that the polarisation of a particle, in extinction and absorption, is usually considered as proportional to (σ_ext,⊥ − σ_ext,∥)/2 and (σ_abs,⊥ − σ_abs,∥)/2, respectively (e.g. Guillet et al. 2018), we defined a fractional polarisation, f_pol, in extinction as $$\begin{array}{rl}{f}_{\mathrm{p}\mathrm{o}\mathrm{l}}& =\frac{\frac{2}{3}{\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t},\perp }-\frac{1}{3}{\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }}{\frac{2}{3}{\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t},\perp }+\frac{1}{3}{\sigma }_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }}=\frac{2\pi ab{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\perp }-\pi b^2{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }}{2\pi ab{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\perp }+\pi b^2{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }}\\ \\ & =\frac{2a{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\perp }-b{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }}{2a{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\perp }+b{Q}_{\mathrm{e}\mathrm{x}\mathrm{t},\parallel }}.\end{array}$$(40)

4 Results and comparisons

One of the major motivations for this work was to provide an efficient means to calculate the long-wavelength (λ ≳ 8 m) optical properties (extinction, absorption, scattering, and polarisation) of spheroidal CM grains within the THEMIS interstellar dust model framework⁷ (Jones et al. 2013, 2017; Köhler et al. 2014) and its updated version THEMIS 2.0 (Ysard et al. 2024). We used the 10 K amorphous silicate (a-Sil) optical constants derived by Demyk et al. (2022) for a mix of 80% forsterite-type and 10% of each of the enstatite-type silicates. This is the amorphous silicate mix a-Sil-1 of THEMIS 2.0, which was adopted for the method comparisons and is not meant as a test of THEMIS 2.0. For hydrogenated amorphous carbon, a-C(:H), we used the optical constants of Jones (2012a,b,c), and for the a-C mantle material we adopted a size-dependent effective band gap of 0.1 eV equivalent to radii of 2.5 nm and 10 nm, that is, half of the mantle depth of 5 nm on a-Sil and 20 nm on a-C:H, as proposed by Jones et al. (2013)⁸. Thus, and as per the THEMIS nomenclature, the considered spheroidal CM particle structures, with confocal mantles, are a-Sil/a-C and a-C:H/a-C with effective radii and mantle depths a_eff/d of 145 nm/5 nm and 130 nm/20 nm, respectively.

The DDA (Purcell & Pennypacker 1973) was used to calculate the grain absorption and scattering efficiencies, with version 7.3.3 of the DDSCAT routine (Draine & Flatau 1994, 2008; Flatau & Draine 2012). In the DDA the grain is assumed to be accurately represented by an assembly of point-like electric dipole oscillators with the dipole size, δ, set according to the following criterion: |m|2πδ/λ < 1/2, where m is the material complex refractive index. The absorption and scattering efficiencies must be averaged over the grain’s spinning dynamics: the DDSCAT routine calculates these efficiencies by varying the grain’s orientation relative to the incident electromagnetic wave. Taking advantage of the symmetries of spheroidal grains, this is simply done using 10 rotation steps each of angle of 10°. Full details of the grain orientations and rotations are given in Sect. 3 of Ysard et al. (2024).

In the following we compare the different methods (analytical, DDSCAT, and EMT) by assuming a core+mantle effective radius a_eff = (a b²)^1/3 = [(a_c + d)(b_c + d)²]^1/3 with d the mantle depth. The core and mantle volumes, V_c and V_M respectively, are $$V_c=(4/3)\pi {(a_{\mathrm{e}\mathrm{f}\mathrm{f}}-d)}^3\text{\hspace{0.17em}and\hspace{0.17em}}{V}_m=(4/3)\pi [a_{\mathrm{e}\mathrm{f}\mathrm{f}}^3-{(a_{\mathrm{e}\mathrm{f}\mathrm{f}}-d)}^3].$$(41)

For a given effective radius particle the core and mantle volumes are the same for each particular spheroid ellipticity and mantle depth case, that is, co-axial, confocal, or constant-depth mantles, and also for the mantled spheres, and are therefore independent of the particle axis ratio (a/b) with the effective radii normalisations. Then, given that $$\begin{array}{rl}& V=\frac{4}{3}\pi a_{\mathrm{e}\mathrm{f}\mathrm{f}}^3=\frac{4}{3}\pi \left(a{b}^2\right),\text{for a given}e=(a/b)\\ & \text{it follows that}a=e^{\frac{2}{3}}{a}_{\mathrm{e}\mathrm{f}\mathrm{f}}\text{and}b=e^{-\frac{1}{3}}{a}_{\mathrm{e}\mathrm{f}\mathrm{f}}.\end{array}$$(42)

Substituting the above in Eq. (39) the equally weighted cross-sections can generically be re-written as $$⟨{\sigma }_i⟩=\frac{1}{3}\pi a^2+\frac{2}{3}\pi (ab)=\frac{\pi a^2}{3}\frac{1}{e}(e+2)=\frac{\pi a_{\mathrm{e}\mathrm{f}\mathrm{f}}^2}{3}{e}^{\frac{1}{3}}(e+2),$$(43)

where i = abs or sca. Normalising to unit effective radius, that is, a_eff = 1, and as per Fig. 3 setting $e=\frac{1}{2},\frac{2}{3},1,\frac{3}{2}$ and 2 yields ⟨σ_i⟩/π = 0.66, 0.78, 1, 1.34, and 1.68, respectively. In other words, the net geometric cross-sections for equal volume and equal axis-weighted oblate and prolate spheroids are decreased and enhanced, respectively, in comparison with a mantled spherical particle with the same core and mantle volumes. Added to this, however, are the effects of the optical properties, Q_abs and Q_sca, which act differentially on the total cross-sections and can reduce or amplify the magnitude of these differences depending on the parallel or perpendicular directions (see Fig. 3).

With thin mantles (d < (a_c + 2b_c)/3), as is typically the case for CM interstellar grains, there is little discernible difference between the results for co-axial, confocal and constant-depth mantles when the parallel and perpendicular factors are combined.That this must be so can be surmised from the L_i factors plotted in Fig. 1 (for a/d = 3) because for even thinner mantles (i.e. a/d > 30) the differences between the core and core+mantle L_i factors for all mantle forms will be considerably smaller.

Setting the core and mantle to the same material and comparing with the exact calculations using the BHCOAT routine (Bohren & Huffman 1998) for spherical CM particles (a = b), yields exactly the same results. For the same materials and the same axis ratio (a/b) the spheroid CM calculations also give the same results as for homogeneous spheroids with a ≠ b.

Fig. 3 Spheroid and coated sphere Qabs and Qsca factors, the latter multiplied by 3 × 104 for clarity, for the parallel (solid lines) and perpendicular (dashed lines) cases, normalised to the same core and mantle volumes. The data shown are for amorphous silicate (a-Sil) cores (effective radius 80 nm) with 20 nm deep aromatic-rich carbon (a-C) mantles (assumed radius of 10 nm; see Sect. 4), as a function of wavelength and e = (ac/bc) = 0.5, 0.667, 1, 1.5, and 2 for co-axial (black), constant-depth (blue), and confocal (red) mantles. Also shown for comparison are the data for mantled spheres (cobalt) of outer effective radius aeff = 80 + 20 = 100 nm.

Fig. 4 Optical properties, Qabs and Qsca, for spheroid and coated spheroid, parallel (thin lines) and perpendicular (thick lines), for amorphous silicate (a-Sil) particles of aeff = 150 nm with 5 nm deep a-C confocal mantles, for oblate and prolate particle axis ratios of 1.3 and 2. The key parameters indicate on each sub-plot. The horizontal bands in the lower part of each plot show the ratio of the Qabs values for DDA/analytic (red) and EMT/analytic (green). The horizontal bands delimit difference factor ranges of 0.9–1.1 (yellow), 0.7–1.3 (grey), and 0.5–2 (orange).

4.1 Comparison with DDSCAT results

In order to be able to compare our analytical results with the numerical results of the DDSCAT code (Draine & Flatau 2000), we did not use the $\frac{2}{3}$_⊥ and $\frac{1}{3}$_∥ simplification in the cross-section calculations, as detailed above, but calculated them via integration over rotation about the principal axes. The cross-sections were fixed for spheroid rotation about the a and c′ axes, that is, σ_i = πab in both cases, and therefore only integration about the b axis is required. The cross-section integration is ideally performed as follows $$\begin{array}{rl}& ⟨{\sigma }_i⟩=\frac{1}{3}[2{\sigma }_{\perp ,i}(ab)Q_{\perp ,i}(ab)+{\int }_0^{\pi /2}{\sigma }_{\parallel ,i}(\theta )Q_i(\theta )d\theta ]\text{\hspace{0.17em}and\hspace{0.17em}}\\ \\ & {\sigma }_{\parallel ,i}(\theta )=\pi b\sqrt{}[a^2{\cos }^2\theta +b^2{\sin }^2\theta ]=\pi bA,\end{array}$$(44)

where $A=\sqrt{}[a^2{\cos }^2\theta +b^2{\sin }^2\theta ]$ is the projection of the semi-axis a onto the ac′ plane (that is for θ = 0). The term σ_∥,i(θ) takes the expected limiting values of πab for θ = 0 and πb² for θ = π/2. This exact form of the integral requires that the efficiency factor Q_i(θ) is known for any arbitrary angle θ. However, for the analytical method adopted here Q_i is only determinable in the orthogonal ⊥ and ∥ directions (see above), and so the cross-section at each angle step is taken to be an angle-weighted sum of the Q_⊥,i and Q_∥,i factors. This is achieved by replacing the integral with a sum over N_θ steps each of weight $N_{\theta }^{-1}$ as follows: $$\begin{array}{rl}& {\sigma }_{\parallel ,i}(\theta )=\frac{1}{N_{\theta }}\sum _0^{\pi /2}[f_a{Q}_{\perp ,i}+f_b{Q}_{\parallel ,i}]\\ \\ & \text{\hspace{0.17em}where\hspace{0.17em}}{f}_a=(\frac{A}{b}-1)\text{\hspace{0.17em}and\hspace{0.17em}}{f}_b=(1-f_a).\end{array}$$(45)

We find that 40 rotation angle steps about the b axis (N_θ = 40) are sufficient to achieve satisfactory convergence. In the DDSCAT calculations only ten angle steps about the b axis were taken due to computational time limitations, which accounts for some small differences in the comparison results but otherwise has little effect.

We compared the mantled spheroid analytical method results with those generated by the DDSCAT tool (Draine & Flatau 2000) for particles with sufficient volume resolution to ensure a close representation of the exact spheroidal forms. For coated spheres we could make comparisons with the Mie routine BHCOAT provided by Bohren & Huffman (1998). In the case of spherical CM particles the three methods agree to within 3% over the 5–300 μm wavelength range and to within 10% out to centimetre wavelengths. For spheroidal CM particles in a comparison of the analytical results with those of DDSCAT, as presented in Figs. 4 and 5, we find that the shortest wavelength to which the long-wavelength analytical method can reliably be applied is λ_lim ≃ 8 μm and good for all λ > 8 μm (see Figs. 4 and 5).

Given that the THEMIS large silicate and carbon grain log-normal distributions peak at radii close to 140 and 160 nm, respectively (Jones et al. 2017), we used 150 nm as a standard test radius and considered 5 nm and 20 nm confocal a-C mantles on a-Sil and a-C:H cores, as used in our DDSCAT calculations. The DDSCAT results and those for the long-wavelength analytical method, for λ = 1–1000 μm, for 150 nm CM grains of a-Sil/a-C are shown in Fig. 4 and those for a-C:H/a-C shown in Fig. 5. We note that while the analytical method provides exact solutions for CM spheroids DDSCAT can, at best, only ever provide good approximations to these perfect shapes. We find intrinsic discrepancies between DDSCAT and the exact analytical method of the order of 10% overall; typically 3 to 6% for the a-Sil/a-C and mostly within 4 to 15% (always ⩽26%) for the a-C:H/a-C CM particles⁹. In most cases the differences are relatively small but do increase at millimetre to centimetre wavelengths. The differences between the methods for other thin-mantled a-Sil/a-C grains are similar in magnitude and do not depend upon axis ratio (a/b), or oblate or prolate form. For the a-C:H/a-C grains the differences are about a factor of 2 larger.

The agreement between the analytical and DDSCAT results is better for thin-mantled silicate spheroids than it is for thick-mantled carbon grains. The discrepancies for the latter increase with increasing wavelength, which may arise because the thicker mantles are more coarsely discretised in the DDSCAT calculations and do not sufficiently resolve the mantles. For example, mantle depth to radius ratios of 0.07–0.4 can impose prohibitively time-consuming computations¹⁰.

We note that the addition of fixed depth a-C mantles onto a-Sil cores essentially adds a constant slope in a log-log plot, with a power law index of ≃1–1.5, to the silicate Q_abs, an effect that is obviously more pronounced for smaller particles. The net result is that of a diminution of silicate features in the a-Sil/a-C spheroids through a reduced band-to-continuum contrast, which will be more pronounced the smaller the spheroid because of the increased mantle volume with respect to the core.

Figure 6 show the polarisation behaviour of the same particles shown in Figs. 4 and 5. From Fig. 6 it can be seen that, for a-Sil/a-C particles with 5 nm a-C mantles the polarisation is rather flat from FIR to centimetre wavelengths, while for a-C:H/a-C particles with 20 nm mantles the quasi-flat polarisation behaviour extends down to IR wavelengths. The degree of polarisation over these same wavelength ranges increases with the transition from prolate to oblate form with polarisations ≃10, 25, 40, and 50% for a/b = 2, 1.3, 0.8, and 0.5, for prolate 2, prolate 1.3, oblate 1.3, and oblate 2, respectively, with only relatively small differences between the two very different particle compositions.

It therefore appears that the degree of polarisation for both a-Sil and a-C:H a-C mantled grains is more sensitive to the particle shape than it is to the core composition or the mantle thickness.

Fig. 5 Same as Fig. 4 but for amorphous carbon (a-C:H) particles with aeff = 150 nm with 20 nm deep confocal a-C mantles.

Fig. 6 Wavelength-dependent polarisation factors, expressed as a percentage and as defined by Eq. (40), for the particles shown in Fig. 4 for a-Sil/a-C particles (solid lines) and in Fig. 5 for a-C:H/a-C particles (dashed lines) for aeff = 150 and oblate particle axis ratios of 1.3 (green) and 2 (blue) and prolate particle axis ratios of 1.3 (red) and 2 (violet) for confocal mantles. The long and short dashed grey lines indicate polarisation levels of 25% and 50%.

4.2 Comparison with volume-normalised coated spheres

Within the framework of the THEMIS model it is useful and interesting to have some idea of the likely effects of non-sphericity on CM grain particles. In order to estimate this, we compared the exact Mie calculations for mantled spheres and spheroids with the same core and mantle volumes. The dashed black lines in Figs. 4 and 5 show the results for the mantled spheres. For the a-C carbon-mantled a-Sil and a-C:H particles the coated sphere results closely follow those of the mantled spheroids with no discernible differences in the wavelength-dependent behaviour. Thus, and apart from furnishing no polarisation data, mantled spheres would appear to provide a good representation of the optical properties of carbon-mantled spheroids.

4.3 Comparison with a volume-normalised, effective medium, volume-averaging method

A commonly used technique in deriving the optical properties of bi-component dust particles, or even multi-coated particles (Jones 2011), is to use an EMT to average the complex dielectric function of the components. In this context, perhaps the most useful is the Bruggemann EMT (Bruggemann 1935), which derives an effective dielectric function, ϵ_av, for a fractional volume of inclusions f_i of dielectric function ϵ_i in a matrix of dielectric function ϵ_m. The effective dielectric function is found by solving the Bruggemann equation: $$f_i\left[\frac{{ϵ}_i-{ϵ}_{av}}{{ϵ}_i+2{ϵ}_{av}}\right]+(1-f_i)\left[\frac{{ϵ}_m-{ϵ}_{av}}{{ϵ}_m+2{ϵ}_{av}}\right]=0.$$(46)

Unlike the Maxwell–Garnett EMT (Garnett 1904) the Bruggemann equation is symmetric about the interchange of inclusions and matrix. For a binary mix Eq. (46) requires solving a quadratic equation or higher order polynomials for more than two components (e.g. Jones 2011). However, the Bruggemann equation can be applied to more than binary mixtures, as pointed out by Jones (2011), if the equation is applied recursively starting with the most refractory of the component materials and proceeding to the least refractory in a pair-wise manner.

The results for Bruggemann EMT-averaged homogeneous spheroids are shown by the thin and thick green lines in Figs. 4 and 5. The EMT, DDSCAT, and analytical method results compare well for a-Sil/a-C particles (Fig. 4) over a wide range of radii (a_eff = 50–300, only the 150 nm data are shown here). Thus, we find a good agreement between all of the methods for thin absorbing mantles on spheroidal refractory amorphous silicate cores, where the mantle/(core+mantle) volume ratio is 0.27, 0.10, and 0.05, for a_eff = 50, 150, and 300 nm, respectively. For the 150 nm a-C:H/a-C particles (Fig. 5) we find that the absorption efficiency factor, Q_abs, is underestimated by at least 50% for the EMT method. For the equivalent 50 nm particles the Q_abs (not shown) is generally good to within ±10%. However, for 300 nm radius grains Q_abs is systematically underestimated by an order of magnitude or more at millimetre to centimetre wavelengths. For these particles the mantle/(core+mantle) volume ratio is 0.78, 0.35, and 0.19, for a_eff = 50, 150, and 300 nm, respectively. Thus, it would seem that in the spheroidal a-C:H/a-C CM EMT calculations, for a fixed depth (20 nm) absorbing mantle, the discrepancy increases significantly with increasing radius, with the absorption properties always systematically underestimated by the EMT method.

An explanation for the unsatisfactory EMT results for thick absorbing mantles on grains, which must also equally well apply to spherical as well as spheroidal particles, lies in a dilution effect that leads to an underestimate of the effects of the mantle contribution to the optical properties in absorption. The averaging of the dielectric functions of the component parts of a particle to yield an effective dielectric function was designed to apply to intimate but distinct component mixes, such as inclusions within a matrix rather than more macroscopically distinct CM structures. When applied to the latter, the dielectric function of the mantle is diluted into that of the core, which may have a very different dielectric function¹¹.6 What this does is underestimate the effects of a surrounding mantle, which in a CM particle can dominate the optical properties and effectively shield the core. This effect explains why, for a fixed mantle depth, the underestimate of the absorption properties increase with size. This is due to an increasing dilution of the core dielectric function into that of the core, with increasing size, in any effective medium treatment.

The Bruggemann EMT and Maxwell–Garnett EMT methods should therefore not be applied to the case of thick, absorbing mantles on refractory cores. More generally, EMT methods will always give unreliable results in the case of CM particle structures, be they spheres, spheroids, or of any arbitrary shape, where there is a large difference in the dielectric functions of the core and the mantle materials.

5 Summary and concluding remarks

The analytical methods developed here to derive the long-wavelength optical and polarisation properties of coated spheroidal particles, of arbitrary semi-axis ratios, provide exact mathematical solutions for their extinction, absorption, scattering, and polarisation properties. These same properties can be calculated with, albeit more time-consuming, numerical methods such as DDSCAT (Draine & Flatau 2000), which have been used to approximate these same mathematical shapes using volume element discretisation. However, interstellar grains are quite clearly not exact nor perfect mathematical figures, and so comparison with the DDSCAT results can be used to give us some idea about the likely uncertainties that should be associated with the analytically calculated spheroid optical properties as applied to real interstellar grains. One obvious advantage of the heavier numerical methods is that, unlike the method developed here, they can be used to study arbitrary shapes, structures, and compositions down to UV wavelengths.

In the analysis presented here we find good agreement between the analytical and DDSCAT methods for wavelengths ⩾ 8 μm for 5 nm carbon-mantled (a-C) amorphous silicate particles (a-Sil), with differences of generally less than ±6% from IR to centimetre wavelengths. For hydrogenated amorphous carbon particles with 20 nm aromatic-rich a-C mantles on aliphaticrich a-C:H cores, the differences are about a factor of 2 larger. In both cases, the differences tend to increase with increasing wavelength. Thus, the analytical method developed here and the numerical DDSCAT calculations show good agreement for the particle absorption and scattering properties of CM particles. The discrepancies between the exact analytical method for perfect spheroids and that for the more irregular voxelated spheroids imply that the uncertainties in the optical properties used by dust models are of the order of ±10% overall – typically within a few percent at IR wavelengths but up to ±25% at millimetre to centimetre wavelengths. These are the intrinsic uncertainties due to the inexactitudes in modelling the unknown interstellar grain shapes and structures within the framework of any particular dust model. In this sense, the discrepancies between the studied methods translate into the uncertainties inherent in modelling the irregular nature of real interstellar grains, and it is unlikely that we can realistically do any better than this.

The new analytical method for spheroidal CM particles has a major advantage over numerical methods, such as DDSCAT and T-Matrix, in that it is easy to code and is computationally fast. It can therefore be used to quickly explore a wide parameter space encompassing grain composition, size, spheroidal shape, and mantle composition, form, and depth at IR to centimetre wavelengths (λ = 8–10⁴μm). The resulting optical property and polarisation predictions will be useful in investigating and modelling the dust properties in the diverse diffuse interstellar and circumstellar media in the Milky Way and in extragalactic environments, but may be particularly pertinent in the interpretation of the dust polarisation in planet-forming circumstellar disk observations where CM-type particle structures might be expected.

The analytical method presented here compares extremely well with the coated sphere results derived using the Mie theory, implying that CM spherical particles can be used as a good approximation for CM spheroidal particles. However, this new analytical method has the advantage that it can also be used to calculate the polarisation properties of spheroidal particles.

We have compared the analytical and DDSCAT methods with the Bruggemann EMT dielectric function averaging method and find that for thin mantled particles there is reasonable agreement. However, for thick absorbing mantles the EMT results underestimate the absorption properties by large factors and should therefore not be used in this case. The cause of the large errors is the dilution of the critical absorbing mantle properties into an effective or averaged dielectric function.

We caution against the use of EMT methods for approximating the optical properties of CM particles, of any shape, where the mantles make up a significant fraction of the total volume and where there is a large difference in the core and mantle dielectric functions. For absorbing mantles the absorption properties will always be underestimated, and for absorbing cores they will always be overestimated. Thus, EMT methods are best used with a great deal of caution in the study of particles consisting of cores with encompassing mantles.
