Filamentation of the electromagnetic precursor in relativistic quasi-perpendicular electron-positron shocks
1
Gran Sasso Science Institute, viale F. Crispi 7, L’Aquila 67100, Italy
2
INFN – Laboratori Nazionali del Gran Sasso, via G. Acitelli 22 Assergi 67100, Italy
3
Physics Department, Ben-Gurion University, Be’er-Sheva 84105, Israel
4
Department of Astronomy and Columbia Astrophysics Laboratory, Columbia University, 550 W 120th St, New York NY 10027, USA
5
Center for Computational Astrophysics, Flatiron Institute, 162 5th Avenue, New York NY 10010, USA
6
Graduate School of System Informatics, Kobe University, 1-1 Rokkodai-cho, Nada, Kobe, Hyogo 657-8501, Japan
⋆ Corresponding author: emanuele.sobacchi@gssi.it
Received:
11
June
2025
Accepted:
30
July
2025
We present a scenario that could explain non-thermal particle acceleration in relativistic quasi-perpendicular electron-positron shocks, such as the termination shock of pulsar wind nebulae. The shock produces a strong electromagnetic precursor that propagates into the upstream plasma, which is initially threaded by a uniform background magnetic field. We show that the filamentation instability breaks the precursor into radiation filaments parallel to the shock normal. The transverse scale of the filaments is of the order of a few plasma skin depths. In the shock frame, the bulk Lorentz factor of the upstream plasma is significantly reduced inside the radiation filaments. Then, the instability produces a relativistic shear flow with strong velocity gradients on kinetic scales. The velocity gradients distort the background magnetic field lines and generate a magnetic field component parallel to the shock normal that reverses across each radiation filament, a configuration that could trigger magnetic reconnection in the upstream plasma. These effects may accelerate particles before the plasma enters the shock.
Key words: acceleration of particles / shock waves / pulsars: general
© The Authors 2025
Open Access article, published by EDP Sciences, under the terms of the Creative Commons Attribution License (https://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
This article is published in open access under the Subscribe to Open model. Subscribe to A&A to support open access publication.
1. Introduction
Theoretical models of relativistic quasi-perpendicular electron-positron shocks suggest that diffusive shock acceleration is inhibited because particles sliding along the magnetic field lines cannot cross the shock multiple times. Then, the downstream particles should have a quasi-thermal distribution (Begelman & Kirk 1990; Gallant et al. 1992; Sironi & Spitkovsky 2009). Pulsar wind termination shocks are prototypical examples of such shocks. Multiwavelength observations show that the pulsar wind nebulae are filled with non-thermal particles (Gaensler & Slane 2006; Hester 2008; Bühler & Blandford 2014; Kargaltsev et al. 2015; Reynolds et al. 2017). The hardness of the radio spectrum implies that the acceleration mechanism transfers most of the available energy to a small fraction of the particles, which is not what one would expect in diffusive shock acceleration. However, the morphology of the nebulae indicates that non-thermal particles are accelerated at the termination shock (Komissarov & Lyubarsky 2003, 2004; Del Zanna et al. 2004, 2006; Porth et al. 2014; Olmi et al. 2015). It is clear that theoretical models of shocks lack some key element that allows the acceleration of non-thermal particles.
Most studies attempt to revive particle acceleration by modifying the properties of the upstream plasma. Some possibilities are as follows. (i) The plasma carries alternating magnetic field lines separated by current sheets, which reconnect at the termination shock (Lyubarsky 2003; Pétri & Lyubarsky 2007; Lyubarsky & Liverts 2008; Sironi & Spitkovsky 2011). However, reconnection-driven acceleration of non-thermal particles requires extremely large particle multiplicities. (ii) The plasma is contaminated with protons (Hoshino et al. 1992; Amato & Arons 2006). However, in order to efficiently accelerate the electron-positron pairs, protons should carry a significant fraction of the energy flux, which seems inconsistent with the modeling of pulsar wind nebulae (Bucciantini et al. 2011). (iii) The magnetic field intensity has a large scale gradient in the latitudinal direction (Cerutti & Giacinti 2020). In this scenario, particles are accelerated by shear flow in an elongated cavity that forms in the equatorial region of the shock and by turbulence that develops in the shock downstream.
Another line of research emphasizes the role of the electromagnetic precursor in the shock dynamics. It is now well established that relativistic quasi-perpendicular electron-positron shocks produce strong electromagnetic waves that propagate into the upstream plasma (Langdon et al. 1988; Gallant et al. 1992; Iwamoto et al. 2017, 2018; Plotnikov & Sironi 2019; Babul & Sironi 2020; Margalit et al. 2020; Sironi et al. 2021). The strength parameter of the electromagnetic precursor can be large, namely a0 > 1 (the strength parameter, a0, is defined as the peak transverse component of the particles four-velocity in units of the speed of light). Lyubarsky (2018, 2019) argues that absorption of the strong electromagnetic precursor could accelerate particles. These studies consider synchrotron absorption and induced Compton scattering as absorption mechanisms. However, the applicability of these absorption mechanisms to the termination shock of pulsar wind nebulae is not discussed in detail.
The filamentation of the electromagnetic precursor has received limited attention so far, although Lyubarsky (2018, 2019) correctly argues that filamentation can be important for shock dynamics. The main difficulty is that one should consider the regime of large wave strength parameters, a0 > 1. The filamentation instability has been extensively studied in different fields, including laser-plasma interaction (Kaw et al. 1973; Drake et al. 1974; Max et al. 1974) and fast radio bursts (Sobacchi et al. 2021, 2022, 2023; Ghosh et al. 2022; Iwamoto et al. 2023). These studies focus on the non-relativistic limit a0 ≪ 1. In this limit, the physics of the instability is understood as follows. Modulations of the radiation intensity in the direction transverse to the wave propagation are expected to be unstable because the ponderomotive force pushes particles out of regions where the intensity is enhanced. The resulting modulation of the plasma refractive index creates a converging lens that further enhances the radiation intensity, thus forming a positive feedback loop. In our previous work (Sobacchi et al. 2024b), we studied the filamentation of electromagnetic waves in unmagnetized electron-positron plasmas in the regime a0 > 1. However, our results cannot be applied to the precursor of relativistic shocks, where the upstream plasma is magnetized.
In this paper, we study the filamentation instability in magnetized electron-positron plasmas. We focus on the regime a0 > 1, as appropriate for relativistic shocks. We show that the electromagnetic precursor at the termination shock of pulsar wind nebulae is almost certainly filamented. The instability has important implications for shock dynamics. In the shock frame, the bulk Lorentz factor of the upstream plasma is significantly reduced when the plasma is illuminated by the electromagnetic precursor. Then, the flow becomes sheared when the precursor is filamented. The shear flow distorts the background magnetic field lines and generates a field component parallel to the shock normal that reverses across each radiation filament, potentially triggering magnetic reconnection. Relativistic shear flow and magnetic reconnection may accelerate particles before the plasma enters the shock.
We show that the physics of the filamentation instability can be modified by the presence of a strong background magnetic field. As we explained above, the instability develops because the density of the plasma increases outside radiation filaments and decreases inside the filaments. When the magnetization of the plasma is large, the ponderomotive force is not the main reason why the density is modified. Instead, the dominant effect is the following. Outside radiation filaments the density increases because the tension of the distorted magnetic field lines pushes the plasma in the direction of wave propagation, whereas inside the filaments the density decreases because the direction of the tension force is reversed.
The paper is organized as follows. In Sect. 2, we review the properties of the electromagnetic precursor. In Sect. 3, we derive the equations that govern the evolution of the precursor. In Sect. 4, we calculate the growth rate and the most unstable wave number of the filamentation instability. In Sect. 5, we discuss the implications of the instability for relativistic shocks. In Sect. 6, we summarize our conclusions. Readers not interested in technical details may skip Sects. 3 and 4.
2. Properties of the electromagnetic precursor
The properties of the electromagnetic precursor are extensively discussed in the literature (Langdon et al. 1988; Gallant et al. 1992; Iwamoto et al. 2017, 2018; Plotnikov & Sironi 2019; Babul & Sironi 2020; Margalit et al. 2020; Sironi et al. 2021). In the following, we summarize the available estimates for the frequency and strength parameter of the precursor.
In the pulsar frame, the termination shock is stationary. The pulsar wind has a large Lorentz factor, Γw, with respect to the shock. In the proper frame of the pulsar wind (hereafter, the “wind frame”), the particles ahead of the precursor are at rest. We define the plasma frequency as
, where n0 is the proper positron number density ahead of the precursor, and e and m, respectively, are the charge and the mass of the positron. We define the Larmor frequency as ωL = eBbg/mc, where Bbg is the background magnetic field in the wind frame ahead of the precursor, and c is the speed of light. The bulk Lorentz factor of the downstream plasma with respect to the shock is of the order of
, where the magnetization is defined as σ = ωL2/ωP2.
In the wind frame, the frequency of the precursor is (Iwamoto et al. 2017; Plotnikov & Sironi 2019; Sironi et al. 2021)
When σ > 1, the strength parameter can be presented as a0 ≃ 0.03 Γw, d, where
is the Lorentz factor of the wind with respect to the downstream plasma (Plotnikov & Sironi 2019; Sironi et al. 2021). For a given Γw, d, the strength parameter increases for decreasing magnetization when 0.1 < σ < 1 and then decreases when 10−3 < σ < 0.1 (see Fig. 11 of Iwamoto et al. 2017, and Fig. 8 of Plotnikov & Sironi 2019). In this paper, we assume
which is the exact expression when σ > 1 and is accurate within a factor of a few when 10−3 < σ < 1. Eqs. (1) and (2) are also valid in the regime a0 > 1 (Margalit et al. 2020). In the wind frame, the magnetic field of the precursor, B0 = a0mcω0/e, can be much larger than the background magnetic field. Using Eqs. (1) and (2), one finds
.
In the following, we estimate the frequency and strength parameter of the electromagnetic precursor at the termination shock of the Crab pulsar wind. The Crab pulsar has a period of P = 33 ms and a magnetic moment of μ = 5 × 1030 G cm3. At the light cylinder radius, RLC = cP/2π, the magnetic field in the pulsar frame is BLC = μ/RLC3, and the particle number density is NLC = κNGJ, where NGJ = BLC/ecP is the Goldreich-Julian density (Goldreich & Julian 1969), and κ is the particle multiplicity. Conservation of energy implies κΓw(1 + σ) = eBLCP/4πmc (Kargaltsev et al. 2015). The latter relation can be presented as Γw = 6 × 105(1 + σ)−1κ5−1, where κ5 = κ/105. Then, Eq. (2) implies a0 ≃ 2 × 104(1 + σ)−3/2κ5−1.
The particle multiplicity, κ, and the magnetization at the termination shock, σ, are difficult to calculate from first principles. The modeling of the Crab pulsar wind nebula suggests κ > 105 (Bucciantini et al. 2011), which is consistent with the multiplicity that one would expect from pair production in the pulsar polar cap (Timokhin & Harding 2015, 2019). The magnetization of the upstream plasma at the termination shock, σ, depends on the amount of magnetic energy that is dissipated by reconnection in the wind (Lyubarsky & Kirk 2001; Kirk & Skjæraasen 2003). Recent fully kinetic simulations show that alternating magnetic field lines could reconnect relatively close to the light cylinder (Cerutti et al. 2020). After reconnection occurs, the plasma is threaded by a uniform magnetic field. In the equatorial region, where stripes of alternating magnetic field are roughly symmetric before reconnection occurs, one would expect σ < 1. In any case, the wave strength parameter is large for any reasonable value of κ and σ, since condition a0 > 1 requires κ < 2 × 109(1 + σ)−3/2.
The Crab pulsar wind terminates at the radius RTS = 4 × 1017 cm (Weisskopf et al. 2000). At the termination shock, the proper number density of the positrons is n0 = NLCRLC2/2ΓwRTS2. Taking into account that NLC = κBLC/ecP = 3 × 1011κ5 cm−3, one can calculate the plasma frequency, which is
. Then, from Eq. (1) one finds
.
3. Evolution of the electromagnetic precursor
We consider a linearly polarized quasi-monochromatic wave packet that propagates in a cold magnetized electron-positron plasma. In the wind frame, the wave frequency is ω0, and the wave vector is
. The electric field of the wave is directed along
, and the background magnetic field is directed along
. The wave polarization corresponds to the extraordinary mode, which is the dominant component of the electromagnetic precursor for large magnetization (Sironi et al. 2021).
We work in the frame that moves with the group velocity, k0/ω0, along
(hereafter, the “wave frame”). In our units, the speed of light is c = 1. As discussed by Clemmow (1974), in this frame the wave vector vanishes, and the wave frequency is
In the wave frame, particles ahead of the wave packet have a large four velocity,
, where u0 = k0/ω (the corresponding Lorentz factor is γ0 = ω0/ω). The magnetic field is
. Since in the wave frame the particles ahead of the wave packet are moving, there is an electric field
. Inside the wave packet, the magnetic field can be presented as
, and the electric field can be presented as
, where
is the vector potential of the wave. We work in the Coulomb gauge, which is
. As we demonstrate in Appendix A, the electrostatic potential vanishes because in electron-positron plasmas the wave does not produce any charge separation. As discussed by Bourdier & Fortin (1979), the equation of motion of the particles can be presented as
where
is the four-velocity, and γ± is the Lorentz factor (the plus and minus signs respectively refer to positrons and electrons). The evolution of the proper number density n± is governed by the continuity equation, which is
The evolution of the wave vector potential is governed by Ampère’s law, which is
In Sects. 3.1–3.4, we manipulate Eqs. (4)–(6) to derive the equations that govern the evolution of the wave envelope.
3.1. Weakly non-linear regime
When the Lorentz factor of the particles is nearly constant inside the wave packet (i.e., γ± ≃ γ0 in the wave frame), the non-linear terms of Eqs. (4)–(6) can be treated as a small perturbation, because the current
is roughly proportional to
(Sobacchi et al. 2024a,b). The key condition γ± ≃ γ0 is satisfied when a0 ≪ ω0/max[ωP, ωL] (Sobacchi et al. 2024a). In the weakly non-linear regime, high-order harmonics of the fields can be neglected. Second-order harmonics would be important to calculate non-linear corrections to the dispersion relation. However, these corrections do not affect the filamentation of electromagnetic waves (Sobacchi et al. 2024b). Then, the vector potential can be presented as
where c.c. indicates the complex conjugate of the oscillating term proportional to e−iωt, and the dots indicate high-order harmonics. The complex function
describes the envelope of the wave packet. The strength parameter of the wave is a0 = max[|a|]. We emphasize that we do not assume a0 ≪ 1. The real function
describes the secular evolution of the vector potential. We will show that
does not vanish because the electromagnetic wave compresses the plasma inside the wave packet and consequently amplifies the background magnetic field. The functions a and
vary on spatial and temporal scales ≫1/ω.
As discussed earlier, the particles ahead of the wave packet have a large four-velocity, u0 = k0/ω, in the wave frame. Since we are interested in the weakly non-linear regime where the Lorentz factor of the particles inside the wave packet is nearly constant, the four-velocity can be presented as
where the real function
describes the secular evolution of the four-velocity, and the complex function
describes the envelope of the fast oscillations.
In the following, we study separately the fast oscillations of the physical quantities, which occur on the time scale 1/ω, and their secular evolution. We retain secular terms of the order of
and
, and oscillating terms of the order of
. We neglect oscillating terms of the order of
, which do not affect the filamentation of electromagnetic waves (Sobacchi et al. 2024b). The Lorentz factor can be approximated as
where
denotes the complex conjugate of
.
3.2. Fast oscillations
In the following, we study the fast oscillations of the physical quantities on the time scale 1/ω. We exploit the fact that the spatial derivatives do not affect the fast oscillations because the wave vector vanishes in the wave frame. The proper number density can be presented as
where the real function δn0± describes the secular evolution of the proper number density, and the complex function nf± describes the envelope of the fast oscillations. The function nf± can be determined from Eq. (5). Since spatial derivatives do not affect fast oscillations, the oscillating terms of γ±n± should vanish. Using Eq. (9) to eliminate γ±, one finds
From Eqs. (9) and (12), one finds
From Eqs. (8) and (12), one finds
In Eqs. (12) and (14), we retained oscillating terms of the order of
and
.
3.2.1. Dispersion relation
In the following, we determine the dispersion relation of the wave at leading order (i.e., we neglect the non-linear terms). These terms are important for the evolution of the wave envelope, which is studied in Sect. 3.2.2. First, one should express the fast oscillations of the four-velocity as a function of a. Substituting Eqs. (7), (8), (10) into Eq. (4), neglecting the spatial derivatives, one finds
Then, one should substitute Eqs. (7) and (14) into Eq. (6). On the left-hand side and on the right-hand side, neglecting the non-linear terms, one can approximate respectively
and
, where ufy+ is given by Eq. (15). Then, the dispersion relation is given by
Taking into account that ω2 = ω02 − k02 and γ02ω2 = ω02, one sees that Eq. (16) is equivalent to the standard dispersion relation in the wind frame, which is (ω02 − k02)(1 − ωL2/ω02) = ωP2. For ω0 ≫ ωL, Eq. (16) implies ω ≃ ωP, and therefore γ0 ≃ ω0/ωP.
To derive the dispersion relation, we assumed that the Lorentz factor of the particles inside the wave packet is nearly constant (i.e., γ± ≃ γ0). Eq. (9) shows that the Lorentz factor is nearly constant for ufy± ≪ γ0 and ufz± ≪ γ0. Since for ω0 ≫ ωL Eq. (15) gives uf ± y ≃ ∓a and uf ± z ≃ i(ωL/ωP)a, the condition γ± ≃ γ0 is satisfied for
where a0 = max[|a|]. Eq. (17) has a simple physical interpretation (Sobacchi et al. 2024a). The condition a0 ≪ ω0/ωP implies that in the wind frame the longitudinal velocity of the particles inside the wave packet should be smaller than the group velocity. The condition a0 ≪ ω0/ωL implies that the background magnetic field inside the wave packet, which is amplified by a factor of order a02 in the wind frame, should be smaller than the wave field. We emphasize that Eq. (17) is always satisfied by electromagnetic precursors in relativistic shocks. Taking into account that ω0 and a0 are respectively given by Eqs. (1) and (2), one finds
.
3.2.2. Evolution of the wave envelope
The equation that governs the evolution of the wave envelope on time scales ≫1/ω can be determined by substituting Eqs. (7) and (14) into the y component of Eq. (6). Considering the resonant terms (i.e., the terms proportional to e−iωt, or eiωt), one finds
The first term on the left-hand side of Eq. (18) can be neglected because ∂2a/∂t2 ≪ ω∂a/∂t. In the first term on the right-hand side, one can approximate ufy± ≃ ∓a and ufz± ≃ i(ωL/ωP)a, which follow from Eq. (15) since max[ωP, ωL]≪ω0. In the second term, one should retain the non-linear corrections to ufy+ − ufy−. Substituting Eqs. (7), (8), (10) into Eq. (4), one finds
On the right-hand side of Eq. (19), we approximated u0 ≃ γ0, as appropriate because γ0 ≫ 1. Substituting Eq. (19) into Eq. (18), and using Eq. (16) to eliminate ω, one finds
where we defined
The evolution of the wave envelope is governed by Eq. (20).
3.3. Secular evolution
Studying the secular evolution of the physical quantities is key for the wave envelope, as Eq. (20) depends on the secular variable
. One should substitute Eqs. (7)–(14) into Eqs. (4)–(6) and average over the fast oscillations. We start by considering Ampère’s law. Substituting Eqs. (7) and (14) into Eq. (6), and taking into account that ufy± ≃ ∓a and ufz± ≃ i(ωL/ωP)a, which follow from Eq. (15), one finds
The transverse component of Eq. (22) can be presented as
where we defined
and
. Now we consider the particles equation of motion. Substituting Eqs. (7)-(10) into Eq. (4), and taking into account that ufy± ≃ ∓a and ufz± ≃ i(ωL/ωP)a, one finds
where a* denotes the complex conjugate of a. In the derivation of Eq. (24), we neglected terms of order a02/γ04. It is convenient to present two separate equations for the variables
and
. As we demonstrate in Appendix B, the equation for the evolution of
is
The first term on the right-hand side of Eq. (25) is the ponderomotive force. The equation for the evolution of
is
Finally, we consider the continuity equation. Substituting Eqs. (13)-(14) into Eq. (5), and taking into account that ufy± ≃ ∓a and ufz± ≃ i(ωL/ωP)a, one finds
In the derivation of Eq. (27), we neglected terms of order a02/γ04. It is convenient to present an equation for the variable
, which appears in Eq. (20). One finds
In the following, we make some algebraic manipulations to simplify our set of equations. In Sect. 3.3.1, we study the evolution of the background electromagnetic fields. Then, in Sect. 3.3.2, we study the velocity and density of the fluid.
3.3.1. Background electromagnetic fields
The background electromagnetic fields are described by the function
. To study the secular evolution of the magnetic field, it is convenient to introduce the variable
, or equivalently
Since
, one has
To study the secular evolution of the electric field, it is convenient to introduce the variable
, or equivalently
Since
in the Coulomb gauge, one has
From Eqs. (29) and (31), one finds
It is also convenient to introduce the variable
First, we consider the x component of Eq. (26). Using Eq. (23) to eliminate δu0 + x − δu0 − x and taking into account that ψ0x varies on spatial and temporal scales ≫1/ωP, one sees that terms proportional to δu0 + x − δu0 − x can be neglected. Then, the x component of Eq. (26) can be approximated as
Substituting Eq. (35) into Eq. (33), one finds
Next, we consider the y component of Eq. (26). As we discussed in the derivation of Eq. (35), terms proportional to δu0 + y − δu0 − y can be neglected. Then, one can approximate
Substituting Eq. (37) into Eq. (33), one finds
Substituting Eqs. (35) and (37) into Eq. (32), one finds
Eqs. (30) and (39) can be presented in a more convenient form. Applying the operator ∂/∂t − (u0/γ0)∂/∂z to both sides of Eq. (30), and using Eqs. (36) and (38) to eliminate δωLx and δωLy, one finds
which implies
Similarly, applying the operator ∂/∂t − (u0/γ0)∂/∂z to both sides of Eq. (39), one finds
The evolution of δωLx, δωLy, δωLz, δωEz is governed by Eqs. (36), (38), (41), (42). After determining the solution of these equations, one can calculate δωEx from Eq. (35) and δωEy from Eq. (37).
3.3.2. Velocity and density of the fluid
The velocity and density of the fluid are described by the functions
and
. The transverse component of Eq. (25) gives
where we defined
Using Eq. (C.2) to simplify the right-hand side, the z component of Eq. (25) gives
The evolution of δjz is governed by the z component of Eq. (26), which gives
The evolution of
is governed by Eq. (28), which gives
The evolution of the fluid is governed by Eqs. (43), (45), (46), (47).
3.4. Final set of equations
To simplify the equations that govern the secular evolution of the system, we neglect the time derivative of |a|. This “quasi-static” approximation is extensively used to study the laser-plasma interaction (e.g., Sprangle et al. 1990). The approximation is justified because we work in the frame that moves with the group velocity, where the time derivative of the wave envelope can be neglected. As we demonstrate in Appendix D, the equations that govern the evolution of the system can be approximated as
where we defined
Since we work in the frame that moves with the group velocity of the wave packet, it is interesting to consider the case where the variables δωLz,
, δjz and δρ depend only on z (and are independent of x, y, t). In this approximation, one would recover the results of Sobacchi et al. (2024a).
The evolution of the wave envelope is governed by Eq. (20). Since non-linear terms of order a02/γ02 do not affect the filamentation of electromagnetic waves (Sobacchi et al. 2024b), Eq. (20) is equivalent to
The evolution of the system is governed by Eqs. (48), (49), (50), (51), (53). When the plasma is unmagnetized (i.e., ωL = 0), one would recover the evolution model of Sobacchi et al. (2024b).
4. Filamentation instability
Our final set of equations (i.e., Eqs. 48, 49, 50, 51, 53) have an exact solution, which is
and a = a0 (where a0 is a constant, which we assumed to be real). In the following, we show that this solution is unstable, and the wave breaks into filaments. We study the evolution of a small perturbation of the wave intensity by defining a = a0(1 + δa). It is convenient to derive from Eq. (53) two equations for δa + δa* and δa − δa*, where δa* denotes the complex conjugate of δa. Assuming that δa + δa* and δa − δa* are proportional to
, one finds
To determine the dispersion relation of the filamentation instability, one should use Eqs. (48)–(51) to express δρ as a function of δa + δa*. Taking into account that |a|2 = a02(1 + δa + δa*) at leading order, one finds
The dispersion relation can be determined from Eqs. (54)–(55). One finds
To determine the growth rate of the filamentation instability, one should substitute Ω = −Kz + ΔΩ into Eq. (56) and consider long wavelengths in the longitudinal direction (i.e., Kz ≪ K⊥ and Kz ≪ ΔΩ). First, we consider modes where the perturbation wave vector, K, is parallel to the direction of the background magnetic field. This case corresponds to Ky = 0. The maximal growth rate is given by
and it is achieved for wave numbers
The growth rate, |ΔΩ|, which is given by Eq. (57), is larger by a factor
with respect to our previous study of the filamentation instability in the non-relativistic limit a0 ≪ 1 (Sobacchi et al. 2022). The wave number, Kx, which is given by Eq. (58), is larger by a factor (1 + σ)1/4. The discrepancy is due to the fact that in our previous study we incorrectly neglected the secular evolution of the background magnetic field (our previous results are obtained by assuming δωLz = 0 in Eq. (51)).
In the following, we explain the reason why the growth rate of the filamentation instability is modified for large σ. The instability develops because the plasma density increases outside radiation filaments and decreases inside the filaments. The resulting modulation of the plasma refractive index creates a converging lens that further enhances the radiation intensity inside the filaments, thus forming a positive feedback loop. When σ < 1, density modulations arise because the transverse component of the ponderomotive force pushes the plasma outside radiation filaments (see Eq. (49)). When σ > 1, another effect becomes dominant. The longitudinal component of the ponderomotive force pushes the plasma in the direction of wave propagation, and consequently the plasma is compressed (Gunn & Ostriker 1971; Sobacchi et al. 2024a). When the perturbations of the wave intensity have a small amplitude, the longitudinal component of the ponderomotive force is nearly constant. Since filamentation distorts the background magnetic field lines (see Eq. (48)), there is an additional force acting on the plasma as a result of magnetic tension. Outside radiation filaments, the tension force has the same direction as the ponderomotive force (i.e., the tension force also pushes the plasma in the direction of propagation). Then, the density of the plasma increases as a result of magnetic tension. Instead, inside the filaments the tension force is antiparallel to the direction of propagation, and consequently the density decreases.
Now, we consider modes where K is perpendicular to the direction of the background magnetic field. This case corresponds to Kx = 0. When γ0ΔΩ ≫ ωL, the maximal growth rate is given by
and it is achieved for wave numbers
The condition γ0ΔΩ ≫ ωL is satisfied for ωL/ωP ≪ a0, or equivalently σ ≪ a02. In this case, the wave packet is broken into roughly cylindrical filaments (the axis of the filaments is along the direction of wave propagation). Instead, when σ ≫ a02 modes with Kx = 0 become stable. In this case, the wave packet is broken into slabs perpendicular to the direction of the background magnetic field. Eqs. (59)–(60) are consistent with our previous study of the filamentation instability in the non-relativistic limit a0 ≪ 1 (Sobacchi et al. 2022). Fully kinetic simulations of relativistic quasi-perpendicular shocks show that the electromagnetic precursor is broken into roughly cylindrical filaments when the magnetization of the upstream flow is small, whereas it is broken into slabs when the magnetization is large (Sironi et al. 2021; Iwamoto et al. 2024). These results are consistent with our findings.
Boyd et al. (1987) study the filamentation instability in magnetized electron-proton plasmas in the non-relativistic limit a0 ≪ 1. When K is parallel to the direction of the background magnetic field, the growth rate of the instability and the most unstable wave number increase when the strength of the background magnetic field increases. When K is perpendicular, the growth rate is suppressed when the strength of the background field increases. These results are consistent with our findings.
5. Implications for relativistic shocks
At the termination shock of the Crab pulsar wind, whose properties are summarized in Sect. 2, the electromagnetic precursor is almost certainly filamented. Consider a wave packet of length ∼RTS in the pulsar frame, where the shock is stationary. The wave packet is moving with a Lorentz factor γ0 = ω0/ωP ≃ 3 Γw with respect to the wind (see Eq. (1)). In the wave frame that moves with a Lorentz factor γ0 with respect to the wind, the length of the wave packet is ΔR ∼ γ0RTS/Γw ∼ 3 RTS. For perturbation wave vectors parallel to the background magnetic field, the growth rate of the filamentation instability in the wave frame can be calculated from Eq. (57), which gives
. The instability develops when |ΔΩ|ΔR/c ≳ 10, or equivalently
. Taking into account that
(see Eq. (2)), the latter condition is equivalent to
Taking into account that
, where κ5 = κ/105, and RTS = 4 × 1017 cm, Eq. (61) implies
. Then, the filamentation instability develops even for relatively small particle multiplicities.
As discussed in Sect. 4, perturbation wave vectors perpendicular to the background magnetic field are unstable when σ ≲ a02. Taking into account that a0 ≃ 2 × 104(1 + σ)−3/2κ5−1, the latter condition is equivalent to
, which could be satisfied in the equatorial region of the termination shock. Then, the precursor would be broken into roughly cylindrical filaments.
Filamentation of the electromagnetic precursor has important consequences for shock dynamics (Fig. 1). After the instability reaches the non-linear stage, the radiation intensity could vanish outside the filaments. As we explain below, this would produce a strong velocity shear across each filament, because the bulk velocity of the upstream plasma depends on the local radiation intensity. The four-velocity and Lorentz factor of individual particles can be calculated in the test particle regime, neglecting the background magnetic field in the equation of motion (Sobacchi et al. 2024a). In this case, the solution of the equation of motion is well known (Gunn & Ostriker 1971). In the proper frame of the wind, the y and z components of the four-velocity of the particles are uy±/c = ∓a and uz±/c = a2/2. The Lorentz factor is γ± = 1 + a2/2. The plus and minus signs respectively refer to positrons and electrons, and the vector potential of the electromagnetic wave is amc2/e. In the shock frame, one has
![]() |
Fig. 1. Structure of relativistic quasi-perpendicular electron-positron shocks. For simplicity, we consider a magnetization σ < 1 (the general case is discussed in the text). The upstream plasma is threaded by a uniform background magnetic field. In the shock frame, the plasma has a large Lorentz factor, Γw ≫ 50. The shock produces an electromagnetic precursor with large strength parameter, a0 ≃ 0.03 Γw. The filamentation instability breaks the precursor into radiation filaments (indicated with the yellow regions), whose transverse scale is of the order of a few plasma skin depths. Inside radiation filaments, the bulk Lorentz factor of the plasma decreases to Γbulk ≃ 50, whereas outside filaments one has Γbulk ≃ Γw. The relativistic shear flow distorts the background magnetic field lines and produces a magnetic field component parallel to the shock normal that reverses across each filament (see Eq. (48)). The longitudinal scale of individual radiation filaments can be shorter than the total length of the precursor. In this case, the precursor would be broken into several incoherent filaments along the z direction. |
where
, and a = a0cos ξ. In the shock frame, the phase of the wave is ξ = k0(z − ct)/(1 + βw)Γw, where k0 = ω0/c is the wave vector calculated in the proper frame of the wind (we assumed ω0 ≫ ωP based on Eq. (1)). The bulk velocity of the flow along the shock normal is ⟨vz⟩=⟨uz±/γ±⟩, where the brackets indicate the average over many wavelengths. The bulk velocity can be conveniently approximated in the limit Γw ≫ 1 and Γw ≫ a (the latter inequality is justified based on Eq. (2)). Taking into account that ⟨a2⟩=a02/2, one finds ⟨vz⟩/c = −1 + (1 + a02/2)/2Γw2. The bulk Lorentz factor,
, is given by
Outside radiation filaments, where a0 vanishes, one has Γbulk ≃ Γw. For a0 ≫ 1, inside the filaments the bulk Lorentz factor significantly decreases, and the flow becomes sheared (as discussed in Sect. 2, the condition a0 ≫ 1 is almost certainly satisfied). Taking into account that
(see Eq. (2)), inside the filaments one has
. In the shock frame, the Lorentz factor of the particles, γ±, is nearly unchanged when the plasma is illuminated by the electromagnetic precursor because Γw ≫ a (see Eq. (62)). However, as previously discussed by Lyubarsky (2018), a significant fraction of the bulk kinetic energy of the wind can be transformed into internal energy.
The transverse scale of the filaments can be estimated from Eq. (58), which gives
. Taking into account that
(see Eqs. (1) and (2)), one finds
The transverse scale of the filaments can be larger than our estimate. Fully kinetic simulations show that in the non-relativistic limit a0 ≪ 1 the filaments tend to merge when the instability reaches the non-linear stage (Iwamoto et al. 2023). We cannot capture this effect because our analysis focuses on the initial stages of the instability, when the perturbations of the wave intensity have a small amplitude.
The filamentation instability may be important for the acceleration of the non-thermal particles in relativistic quasi-perpendicular electron-positron shocks. The particles could be accelerated before entering the shock because the upstream flow is sheared, with significant variations of the bulk Lorentz factor on kinetic scales of the order of λx. The scenario is further enriched by the background magnetic field. Eq. (48) shows that the filamentation instability distorts the field lines and generates a magnetic field component parallel to the shock normal that reverses on the scale of the filaments, λx (the source term on the right-hand side of Eq. (48) is proportional to the gradient of the radiation intensity across filaments). Magnetic field reversals on such kinetic scales could trigger reconnection of the field lines, and consequently particles could be accelerated. In the wind frame the background magnetic field lines can be significantly distorted because in this frame the magnetic field of the precursor can be much larger than the background field (one has B0/Bbg = a0ω0/ωL ≃ 3 × 1010σ−1/2(1 + σ)−5/2κ5−2). Instead, in the shock frame the background magnetic field component parallel to the shock normal remains smaller than the perpendicular component.
The shock may exhibit a cyclic behavior. When the upstream plasma is cold, the precursor has a large strength parameter (given by Eq. (2)). As discussed above, particles could be heated/accelerated before the plasma enters the shock. When the upstream plasma is filled with energetic particles, the efficiency of synchrotron maser emission is suppressed (Babul & Sironi 2020), and the strength parameter of the precursor decreases. The weakening of the precursor would suppress the acceleration of the particles, and the cycle would start over because the upstream plasma would be cold.
6. Conclusions
We studied the interaction of a strong electromagnetic precursor with the upstream plasma in relativistic quasi-perpendicular electron-positron shocks. The plasma is initially threaded by a uniform background magnetic field. We showed that the precursor can be broken into radiation filaments parallel to the shock normal. The transverse scale of the filaments is of the order of a few plasma skin depths. Since the bulk Lorentz factor of the plasma depends on the local radiation intensity, the filamentation instability produces a relativistic shear flow, where the bulk Lorentz factor changes significantly across each radiation filament. In the frame of the shock, outside radiation filaments, the bulk Lorentz factor of the plasma is the same as in the absence of the precursor, whereas inside the filaments, the bulk Lorentz factor is significantly reduced. The background magnetic field lines are distorted by the shear flow. Such a distortion produces a magnetic field component parallel to the shock normal that reverses across each filament, a configuration that could trigger magnetic reconnection. Relativistic shear flow and magnetic reconnection may accelerate particles before the plasma enters the shock. Fully kinetic simulations are required to investigate this scenario.
Acknowledgments
We acknowledge insightful discussions with Elena Amato, Pasquale Blasi, Benoît Cerutti and Tsvi Piran. This work was supported by a Rita Levi Montalcini fellowship [E.S.], by the Simons Foundation Grant 00001470 to the Simons Collaboration on Extreme Electrodynamics of Compact Sources (SCEECS) [L.S.], by the DoE Early Career Award DE-SC0023015 [L.S.], by the Multimessenger Plasma Physics Center (MPPC) NSF Grant PHY2206609 [L.S.], by the NSF Grant AST-2307202 [L.S.], by the NASA ATP Grants 80NSSC24K1238 and 80NSSC24K1826 [L.S.], and by the JSPS KAKENHI Grant 22H00130 [M.I.].
References
- Amato, E., & Arons, J. 2006, ApJ, 653, 325 [Google Scholar]
- Babul, A.-N., & Sironi, L. 2020, MNRAS, 499, 2884 [NASA ADS] [CrossRef] [Google Scholar]
- Begelman, M. C., & Kirk, J. G. 1990, ApJ, 353, 66 [NASA ADS] [CrossRef] [Google Scholar]
- Bourdier, A., & Fortin, X. 1979, Phys. Rev. A, 20, 2154 [Google Scholar]
- Boyd, T. J. M., Coutts, G. A., & Marks, D. C. 1987, Phys. Fluids, 30, 533 [Google Scholar]
- Bucciantini, N., Arons, J., & Amato, E. 2011, MNRAS, 410, 381 [NASA ADS] [CrossRef] [Google Scholar]
- Bühler, R., & Blandford, R. 2014, Rep. Prog. Phys., 77, 066901 [NASA ADS] [CrossRef] [Google Scholar]
- Cerutti, B., & Giacinti, G. 2020, A&A, 642, A123 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
- Cerutti, B., Philippov, A. A., & Dubus, G. 2020, A&A, 642, A204 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
- Clemmow, P. C. 1974, J. Plasma Phys., 12, 297 [NASA ADS] [CrossRef] [Google Scholar]
- Del Zanna, L., Amato, E., & Bucciantini, N. 2004, A&A, 421, 1063 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
- Del Zanna, L., Volpi, D., Amato, E., & Bucciantini, N. 2006, A&A, 453, 621 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
- Drake, J. F., Kaw, P. K., Lee, Y. C., et al. 1974, Phys. Fluids, 17, 778 [NASA ADS] [CrossRef] [Google Scholar]
- Gaensler, B. M., & Slane, P. O. 2006, ARA&A, 44, 17 [Google Scholar]
- Gallant, Y. A., Hoshino, M., Langdon, A. B., Arons, J., & Max, C. E. 1992, ApJ, 391, 73 [Google Scholar]
- Ghosh, A., Kagan, D., Keshet, U., & Lyubarsky, Y. 2022, ApJ, 930, 106 [Google Scholar]
- Goldreich, P., & Julian, W. H. 1969, ApJ, 157, 869 [Google Scholar]
- Gunn, J. E., & Ostriker, J. P. 1971, ApJ, 165, 523 [CrossRef] [Google Scholar]
- Hester, J. J. 2008, ARA&A, 46, 127 [Google Scholar]
- Hoshino, M., Arons, J., Gallant, Y. A., & Langdon, A. B. 1992, ApJ, 390, 454 [Google Scholar]
- Iwamoto, M., Amano, T., Hoshino, M., & Matsumoto, Y. 2017, ApJ, 840, 52 [Google Scholar]
- Iwamoto, M., Amano, T., Hoshino, M., & Matsumoto, Y. 2018, ApJ, 858, 93 [Google Scholar]
- Iwamoto, M., Sobacchi, E., & Sironi, L. 2023, MNRAS, 522, 2133 [Google Scholar]
- Iwamoto, M., Matsumoto, Y., Amano, T., Matsukiyo, S., & Hoshino, M. 2024, Phys. Rev. Lett., 132, 035201 [NASA ADS] [CrossRef] [Google Scholar]
- Kargaltsev, O., Cerutti, B., Lyubarsky, Y., & Striani, E. 2015, Space Sci. Rev., 191, 391 [NASA ADS] [CrossRef] [Google Scholar]
- Kaw, P., Schmidt, G., & Wilcox, T. 1973, Phys. Fluids, 16, 1522 [Google Scholar]
- Kirk, J. G., & Skjæraasen, O. 2003, ApJ, 591, 366 [CrossRef] [Google Scholar]
- Komissarov, S. S., & Lyubarsky, Y. E. 2003, MNRAS, 344, L93 [NASA ADS] [CrossRef] [Google Scholar]
- Komissarov, S. S., & Lyubarsky, Y. E. 2004, MNRAS, 349, 779 [NASA ADS] [CrossRef] [Google Scholar]
- Langdon, A. B., Arons, J., & Max, C. E. 1988, Phys. Rev. Lett., 61, 779 [CrossRef] [Google Scholar]
- Lyubarsky, Y. E. 2003, MNRAS, 345, 153 [Google Scholar]
- Lyubarsky, Y. 2018, MNRAS, 474, 1135 [Google Scholar]
- Lyubarsky, Y. 2019, MNRAS, 490, 1474 [Google Scholar]
- Lyubarsky, Y., & Kirk, J. G. 2001, ApJ, 547, 437 [NASA ADS] [CrossRef] [Google Scholar]
- Lyubarsky, Y., & Liverts, M. 2008, ApJ, 682, 1436 [NASA ADS] [CrossRef] [Google Scholar]
- Margalit, B., Metzger, B. D., & Sironi, L. 2020, MNRAS, 494, 4627 [Google Scholar]
- Max, C. E., Arons, J., & Langdon, A. B. 1974, Phys. Rev. Lett., 33, 209 [Google Scholar]
- Olmi, B., Del Zanna, L., Amato, E., & Bucciantini, N. 2015, MNRAS, 449, 3149 [Google Scholar]
- Pétri, J., & Lyubarsky, Y. 2007, A&A, 473, 683 [Google Scholar]
- Plotnikov, I., & Sironi, L. 2019, MNRAS, 485, 3816 [NASA ADS] [CrossRef] [Google Scholar]
- Porth, O., Komissarov, S. S., & Keppens, R. 2014, MNRAS, 438, 278 [Google Scholar]
- Reynolds, S. P., Pavlov, G. G., Kargaltsev, O., et al. 2017, Space Sci. Rev., 207, 175 [NASA ADS] [CrossRef] [Google Scholar]
- Sironi, L., & Spitkovsky, A. 2009, ApJ, 698, 1523 [NASA ADS] [CrossRef] [Google Scholar]
- Sironi, L., & Spitkovsky, A. 2011, ApJ, 741, 39 [Google Scholar]
- Sironi, L., Plotnikov, I., Nättilä, J., & Beloborodov, A. M. 2021, Phys. Rev. Lett., 127, 035101 [NASA ADS] [CrossRef] [Google Scholar]
- Sobacchi, E., Lyubarsky, Y., Beloborodov, A. M., & Sironi, L. 2021, MNRAS, 500, 272 [Google Scholar]
- Sobacchi, E., Lyubarsky, Y., Beloborodov, A. M., & Sironi, L. 2022, MNRAS, 511, 4766 [NASA ADS] [CrossRef] [Google Scholar]
- Sobacchi, E., Lyubarsky, Y., Beloborodov, A. M., Sironi, L., & Iwamoto, M. 2023, ApJ, 943, L21 [Google Scholar]
- Sobacchi, E., Iwamoto, M., Sironi, L., & Piran, T. 2024a, A&A, 690, A332 [NASA ADS] [CrossRef] [EDP Sciences] [Google Scholar]
- Sobacchi, E., Iwamoto, M., Sironi, L., & Piran, T. 2024b, Phys. Rev. Res., 6, 043213 [Google Scholar]
- Sprangle, P., Esarey, E., & Ting, A. 1990, Phys. Rev. Lett., 64, 2011 [NASA ADS] [CrossRef] [Google Scholar]
- Timokhin, A. N., & Harding, A. K. 2015, ApJ, 810, 144 [NASA ADS] [CrossRef] [Google Scholar]
- Timokhin, A. N., & Harding, A. K. 2019, ApJ, 871, 12 [NASA ADS] [CrossRef] [Google Scholar]
- Weisskopf, M. C., Hester, J. J., Tennant, A. F., et al. 2000, ApJ, 536, L81 [NASA ADS] [CrossRef] [Google Scholar]
Appendix A: Electrostatic potential
In the following, we demonstrate that the electrostatic potential vanishes in the wave frame. Using Eq. (13), and taking into account that |ufy+|=|ufy−| and |ufz+|=|ufz−|, the charge density can be presented as
The evolution of the charge density can be studied using Eq. (27), which gives
Eq. (A.2) can be simplified as follows. One can use Eq. (23) to express
as a function of
. Then, one can use the gauge condition, which is
, to eliminate
. Finally, one can use the z component of Eq. (22) to eliminate ψ0z. This procedure gives
From Eqs. (A.1) and (A.3), one finds ∂(γ+n+ − γ−n−)/∂t = 0, which implies γ+n+ = γ−n−. The electrostatic potential, ϕ, is governed by Gauss’s law, which is ∇2ϕ = −4πe(γ+n+ − γ−n−). Since γ+n+ = γ−n−, one finds ϕ = 0.
Appendix B: Fluid velocity
The equation that governs the evolution of
can be derived from Eq. (24). One finds
Taking into account that
for any function f, and using Eq. (23) to express
as a function of
, one sees that Eq. (B.1) is equivalent to Eq. (25). The equation that governs the evolution of
is
which is equivalent to Eq. (26).
Appendix C: A useful identity
To simplify the right-hand side of Eq. (25), one can use the identity demonstrated below. The gauge condition
implies ∂2ψ0y/∂y2 = −∂2ψ0x/∂x∂y − ∂2ψ0z/∂y∂z. Using the latter identity, and taking into account that δωLx = ∂ψ0z/∂y − ∂ψ0y/∂z and δωLz = ∂ψ0y/∂x − ∂ψ0x/∂y, one can show that ∇2ψ0y = ∂δωLz/∂x − ∂δωLx/∂z. Since ∂ψ0y/∂t = −δωEy, one finds
Now, we can use Eq. (37) to eliminate δωEy and then Eq. (38) to eliminate ∂δωLx/∂t. This procedure gives
Appendix D: Final set of equations
In the following, we derive Eqs. (48)-(51). Neglecting the time derivative of |a|, and taking into account that u0 ≃ γ0, Eq. (42) can be approximated as
We introduce an additional approximation and neglect terms of the order of δvz/γ02, as appropriate because γ0 ≫ 1. In this approximation, Eq. (D.1) gives δωEz ≃ 0. Substituting δωEz ≃ 0 into Eq. (36), one finds δωLy ≃ 0. Substituting δωEz ≃ 0 into Eq. (38), and neglecting terms of the order of δvz/γ02, one finds
Neglecting the time derivative of |a|, Eq. (D.2) gives δωLx/γ0ωL ≃ |a|2/4γ02.
Eq. (41) is equivalent to Eq. (48) because terms of order δvz/γ02 can be neglected. Eq. (43) is clearly equivalent to Eq. (49). Taking into account that δωEz ≃ 0, Eq. (46) can be presented as
The second term on the right-hand side of Eq. (D.3) can be neglected because the wave envelope, a, varies on spatial scales ≫1/ωP. In this limit, Eq. (D.3) is equivalent to Eq. (50).
It is convenient to derive a new equation for the evolution of
by adding Eqs. (45) and (47). Neglecting terms of the order of δvz/γ02, and taking into account that δωEz ≃ 0, one finds
Taking into account that δωLx/γ0ωL ≃ |a|2/4γ02, one sees that the last term on the right-hand side of Eq. (D.4) can be neglected, as it is of order a02/γ04. Then, Eq. (D.4) can be presented as
where δρ is defined by Eq. (52). Since the time derivative of |a| can be neglected, Eq. (D.5) is equivalent to Eq. (51).
All Figures
![]() |
Fig. 1. Structure of relativistic quasi-perpendicular electron-positron shocks. For simplicity, we consider a magnetization σ < 1 (the general case is discussed in the text). The upstream plasma is threaded by a uniform background magnetic field. In the shock frame, the plasma has a large Lorentz factor, Γw ≫ 50. The shock produces an electromagnetic precursor with large strength parameter, a0 ≃ 0.03 Γw. The filamentation instability breaks the precursor into radiation filaments (indicated with the yellow regions), whose transverse scale is of the order of a few plasma skin depths. Inside radiation filaments, the bulk Lorentz factor of the plasma decreases to Γbulk ≃ 50, whereas outside filaments one has Γbulk ≃ Γw. The relativistic shear flow distorts the background magnetic field lines and produces a magnetic field component parallel to the shock normal that reverses across each filament (see Eq. (48)). The longitudinal scale of individual radiation filaments can be shorter than the total length of the precursor. In this case, the precursor would be broken into several incoherent filaments along the z direction. |
| In the text | |
Current usage metrics show cumulative count of Article Views (full-text article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 48-96 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.



![$$ \begin{aligned} \frac{\partial }{\partial t}\left({\boldsymbol{u}}_\pm \pm \tilde{\boldsymbol{a}}\right) -\frac{{\boldsymbol{u}}_\pm }{\gamma _\pm } \times \left[\nabla \times \left({\boldsymbol{u}}_\pm \pm \tilde{\boldsymbol{a}} \right)\right] = -\nabla \gamma _\pm \pm \left(\frac{{\boldsymbol{u}}_\pm }{\gamma _\pm }+\frac{u_0}{\gamma _0}{\boldsymbol{e}}_z\right)\times \gamma _0\omega _{\rm L}{\boldsymbol{e}}_x , \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq21.gif)




![$$ \begin{aligned} \frac{\gamma _\pm }{\gamma _0} = 1 -\frac{u_0}{\gamma _0}\frac{\delta u_{0z\pm }}{\gamma _0} + \frac{\left|{\boldsymbol{u}}_{\rm f\pm }\right|^2}{4\gamma _0^2} -\frac{u_0^2}{\gamma _0^2}\frac{\left| u_{\mathrm{f}z\pm }\right|^2}{4\gamma _0^2} -\left[\frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm }}{2\gamma _0} \left(1+ \frac{u_0}{\gamma _0}\frac{\delta u_{0z\pm }}{\gamma _0} \right) - \frac{{\boldsymbol{u}}_{\mathrm{f}\pm }\cdot \delta {\boldsymbol{u}}_{0\pm }}{2\gamma _0^2} \right] \mathrm{e}^{-\mathrm{i}\omega t} +\ldots +\mathrm{c.c.} \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq39.gif)
![$$ \begin{aligned} \nonumber \frac{{\boldsymbol{u}}_\pm }{\gamma _\pm } =&-\frac{u_0}{\gamma _0} \left( 1+ \frac{u_0}{\gamma _0}\frac{\delta u_{0z\pm }}{\gamma _0} - \frac{\left|{\boldsymbol{u}}_{\rm f\pm }\right|^2}{4\gamma _0^2} + \frac{u_0^2}{\gamma _0^2}\frac{3\left|u_{\mathrm{f}z\pm }\right|^2}{4\gamma _0^2} \right) {\boldsymbol{e}}_z + \frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0} +\frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm } {\boldsymbol{u}}^*_{\rm f\pm } + u_{\mathrm{f}z\pm }^* {\boldsymbol{u}}_{\rm f\pm }}{4\gamma _0^2} + \\&+ \left[ \frac{{\boldsymbol{u}}_{\rm f\pm }}{2\gamma _0}\left(1 +\frac{u_0}{\gamma _0}\frac{\delta u_{0z\pm }}{\gamma _0} \right) +\frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm }}{2\gamma _0}\frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0} \right] \mathrm{e}^{-\mathrm{i}\omega t} - \left[ \frac{u_0^2}{\gamma _0^2} \frac{u_{\mathrm{f}z\pm }}{2\gamma _0} \left( 1 + \frac{u_0}{\gamma _0}\frac{3\delta u_{0z\pm }}{\gamma _0} \right) -\frac{u_0}{\gamma _0} \frac{{\boldsymbol{u}}_{\mathrm{f}\pm }\cdot \delta {\boldsymbol{u}}_{0\pm }}{2\gamma _0^2} \right] {\boldsymbol{e}}_z \; \mathrm{e}^{-\mathrm{i}\omega t} + \ldots + \mathrm{c.c.} , \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq40.gif)

![$$ \begin{aligned} \frac{n_\pm }{n_0} = 1+\frac{\delta n_{0\pm }}{n_0} + \left[ \frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm }}{2\gamma _0} \left(1 +\frac{\delta n_{0\pm }}{n_0} + \frac{u_0}{\gamma _0}\frac{2\delta u_{0z\pm }}{\gamma _0} \right) - \frac{{\boldsymbol{u}}_{\mathrm{f}\pm }\cdot \delta {\boldsymbol{u}}_{0\pm }}{2\gamma _0^2} \right] \mathrm{e}^{-\mathrm{i}\omega t} +\ldots +\mathrm{c.c.} \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq44.gif)

![$$ \begin{aligned} \nonumber \frac{n_\pm {\boldsymbol{u}}_\pm }{\gamma _0n_0} = -\frac{u_0}{\gamma _0} \left(1+ \frac{\delta n_{0\pm }}{n_0}\right) {\boldsymbol{e}}_z +\frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0}&+ \frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm } {\boldsymbol{u}}^*_{\rm f\pm } + u_{\mathrm{f}z\pm }^* {\boldsymbol{u}}_{\rm f\pm }}{4\gamma _0^2} + \left[ \left(1+\frac{\delta n_{0\pm }}{n_0}\right)\frac{{\boldsymbol{u}}_{\rm f\pm }}{2\gamma _0} + \frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm }}{2\gamma _0} \frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0} \right]\mathrm{e}^{-\mathrm{i}\omega t} +\\&- \frac{u_0}{\gamma _0} \left[ \frac{u_0}{\gamma _0}\frac{u_{\mathrm{f}z\pm }}{2\gamma _0} \left(1+\frac{\delta n_{0\pm }}{n_0} +\frac{u_0}{\gamma _0}\frac{2\delta u_{0z\pm }}{\gamma _0} \right) - \frac{{\boldsymbol{u}}_{\mathrm{f}\pm }\cdot \delta {\boldsymbol{u}}_{0\pm }}{2\gamma _0^2} \right] {\boldsymbol{e}}_z \; \mathrm{e}^{-\mathrm{i}\omega t} +\ldots +\mathrm{c.c.} \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq46.gif)


![$$ \begin{aligned} a_0\ll \frac{\omega _0}{\max \left[\omega _{\rm P},\omega _{\rm L}\right]} , \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq53.gif)
![$$ \begin{aligned} \frac{\partial ^2 a}{\partial t^2}-2\mathrm{i}\omega \frac{\partial a}{\partial t} -\omega ^2 a -\nabla ^2 a = \frac{\omega _{\rm P}^2}{2} \left[ \frac{\delta n_{0+}}{n_0} u_{\mathrm{f}y+} - \frac{\delta n_{0-}}{n_0} u_{\mathrm{f}y-} +\frac{u_0}{\gamma _0} \left(\frac{\delta u_{0y+}}{\gamma _0}u_{\mathrm{f}z+} - \frac{\delta u_{0y-}}{\gamma _0} u_{\mathrm{f}z-} \right) \right] + \frac{\omega _{\rm P}^2}{2} \left( u_{\mathrm{f}y+}-u_{\mathrm{f}y-} \right) . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq55.gif)



![$$ \begin{aligned} \frac{\partial ^2}{\partial t^2}\frac{{\boldsymbol{\psi }}_0}{\gamma _0} - \nabla ^2\frac{{\boldsymbol{\psi }}_0}{\gamma _0} = \frac{\omega _{\rm P}^2}{2} \left[\frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} -\frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0} -\frac{u_0}{\gamma _0}\left(\frac{\delta n_{0+}}{n_0} - \frac{\delta n_{0-}}{n_0} \right){\boldsymbol{e}}_z \right] . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq60.gif)

![$$ \begin{aligned} \nonumber \frac{\partial }{\partial t} \left(\frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0}\pm \frac{{\boldsymbol{\psi }}_0}{\gamma _0} \right) + \frac{u_0}{\gamma _0} {\boldsymbol{e}}_z\times \left[\nabla \times \left(\frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0}\pm \frac{{\boldsymbol{\psi }}_0}{\gamma _0}\right) \right]&\pm \mathrm{i}\frac{\omega _{\rm L}}{\omega _{\rm P}}\left[ \frac{a}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a^*}{2\gamma _0}\right) - \frac{a^*}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a}{2\gamma _0}\right) \right] {\boldsymbol{e}}_z = \\&= -\nabla \left( \frac{\left|a\right|^2}{4\gamma _0^2} -\frac{u_0}{\gamma _0}\frac{\delta u_{0z\pm }}{\gamma _0} \right) \pm \left( \frac{\delta {\boldsymbol{u}}_{0\pm }}{\gamma _0} -\frac{u_0^2}{\gamma _0^2}\frac{\delta u_{0z\pm }}{\gamma _0}{\boldsymbol{e}}_z + \frac{\left|a\right|^2}{4\gamma _0^2}{\boldsymbol{e}}_z \right) \times \omega _{\rm L}{\boldsymbol{e}}_x , \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq64.gif)

![$$ \begin{aligned} \nonumber \frac{\partial }{\partial t} \left(\frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} - \frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0} +\frac{2{\boldsymbol{\psi }}_0}{\gamma _0} \right)&-\frac{u_0}{\gamma _0}\frac{\partial }{\partial z} \left( \frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} - \frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0} +\frac{2{\boldsymbol{\psi }}_0}{\gamma _0} \right) +\frac{u_0}{\gamma _0}\nabla \frac{2\psi _{0z}}{\gamma _0} + \mathrm{i}\frac{2\omega _{\rm L}}{\omega _{\rm P}}\left[ \frac{a}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a^*}{2\gamma _0}\right) - \frac{a^*}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a}{2\gamma _0}\right) \right] {\boldsymbol{e}}_z = \\&= -\left(\frac{\delta u_{0y+}}{\gamma _0}+\frac{\delta u_{0y-}}{\gamma _0}\right)\omega _{\rm L}{\boldsymbol{e}}_z + \frac{1}{\gamma _0^2}\left(\frac{\delta u_{0z+}}{\gamma _0}+\frac{\delta u_{0z-}}{\gamma _0}\right)\omega _{\rm L}{\boldsymbol{e}}_y + \frac{\left|a\right|^2}{2\gamma _0^2}\omega _{\rm L}{\boldsymbol{e}}_y . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq70.gif)















![$$ \begin{aligned} \frac{u_0}{\gamma _0} \left(\frac{\partial ^2\delta \omega _{\mathrm{E}z}}{\partial x^2} + \frac{\partial ^2\delta \omega _{\mathrm{E}z}}{\partial y^2} + \frac{\partial ^2\delta \omega _{\mathrm{E}z}}{\partial z^2} \right) = \frac{\partial }{\partial t} \left[\frac{\partial \delta \omega _{\mathrm{E}z}}{\partial z} -\frac{\partial }{\partial y} \left( \frac{\left|a\right|^2}{4\gamma _0}\omega _{\rm L}+ \frac{\delta v_z}{\gamma _0}\omega _{\rm L} \right) \right] . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq92.gif)



![$$ \begin{aligned} \frac{\partial \delta j_z}{\partial t} - \frac{u_0}{\gamma _0} \frac{\partial \delta j_z}{\partial z} = \frac{\delta \omega _{\mathrm{E}z}}{\gamma _0} -\omega _{\rm L} \delta v_y - \mathrm{i}\frac{\omega _{\rm L}}{\omega _{\rm P}}\left[ \frac{a}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a^*}{2\gamma _0}\right) - \frac{a^*}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a}{2\gamma _0}\right) \right] . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq98.gif)








![$$ \begin{aligned} \left(\Omega +K_z\right)^2 \delta \rho = \left[K_x^2\left(1+\frac{\omega _{\rm L}^2}{\omega _{\rm P}^2}\right) +\frac{K_y^2}{1-\frac{\omega _{\rm L}^2}{\gamma _0^2\left(\Omega +K_z\right)^2}}\right] \frac{a_0^2}{4\gamma _0^2}\left(\delta a+\delta a^*\right) . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq111.gif)
![$$ \begin{aligned} \left(\Omega +K_z\right)^2 \left(\frac{4\Omega ^2}{K^2} - \frac{K^2}{\omega _{\rm P}^2}\right) = \frac{a_0^2}{2\gamma _0^2} \left[K_x^2\left(1+\frac{\omega _{\rm L}^2}{\omega _{\rm P}^2}\right) +\frac{K_y^2}{1-\frac{\omega _{\rm L}^2}{\gamma _0^2\left(\Omega +K_z\right)^2}}\right] . \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq112.gif)






![$$ \begin{aligned} \frac{u_{y\pm }}{c} = \mp a , \qquad \frac{u_{z\pm }}{c} = -\Gamma _{\rm w}\beta _{\rm w} \left[1 - \frac{a^2}{2\Gamma _{\rm w}^2\beta _{\rm w}\left(1+\beta _{\rm w}\right)}\right] ,\qquad \gamma _\pm = \Gamma _{\rm w}\left[1 + \frac{a^2}{2\Gamma _{\rm w}^2\left(1+\beta _{\rm w}\right)}\right] , \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq125.gif)





![$$ \begin{aligned} \nonumber \frac{\partial }{\partial t} \left( \frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} + \frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0} \right)&+\frac{u_0}{\gamma _0} {\boldsymbol{e}}_z \times \left[\nabla \times \left( \frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} + \frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0} \right) \right] = \\&= \nabla \left[ \frac{u_0}{\gamma _0}\left(\frac{\delta u_{0z+}}{\gamma _0} + \frac{\delta u_{0z+}}{\gamma _0}\right) - \frac{\left|a\right|^2}{2\gamma _0^2} \right] + \frac{1}{\gamma _0^2}\left(\frac{\delta u_{0z+}}{\gamma _0}-\frac{\delta u_{0z+}}{\gamma _0}\right)\omega _{\rm L}{\boldsymbol{e}}_y + \left( \frac{\delta {\boldsymbol{u}}_{0\perp +}}{\gamma _0} - \frac{\delta {\boldsymbol{u}}_{0\perp -}}{\gamma _0} \right) \times \omega _{\rm L}{\boldsymbol{e}}_x \;. \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq142.gif)
![$$ \begin{aligned} \nonumber \frac{\partial }{\partial t}&\left(\frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} - \frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0} +\frac{2{\boldsymbol{\psi }}_0}{\gamma _0} \right) +\frac{u_0}{\gamma _0} {\boldsymbol{e}}_z \times \left[\nabla \times \left(\frac{\delta {\boldsymbol{u}}_{0+}}{\gamma _0} - \frac{\delta {\boldsymbol{u}}_{0-}}{\gamma _0}+\frac{2{\boldsymbol{\psi }}_0}{\gamma _0} \right) \right] + \mathrm{i}\frac{2\omega _{\rm L}}{\omega _{\rm P}}\left[ \frac{a}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a^*}{2\gamma _0}\right) - \frac{a^*}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a}{2\gamma _0}\right) \right] {\boldsymbol{e}}_z = \\&= \frac{u_0}{\gamma _0}\nabla \left(\frac{\delta u_{0z+}}{\gamma _0} - \frac{\delta u_{0z-}}{\gamma _0} \right) + \left[\frac{\delta {\boldsymbol{u}}_{0\perp +}}{\gamma _0} + \frac{\delta {\boldsymbol{u}}_{0\perp -}}{\gamma _0} +\frac{1}{\gamma _0^2}\left(\frac{\delta u_{0z+}}{\gamma _0}+\frac{\delta u_{0z-}}{\gamma _0}\right){\boldsymbol{e}}_z +\frac{u_0}{\gamma _0}\frac{\left|a\right|^2}{2\gamma _0^2}{\boldsymbol{e}}_z \right]\times \omega _{\rm L}{\boldsymbol{e}}_x \;, \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq147.gif)




![$$ \begin{aligned} \frac{\partial }{\partial t} \left(\frac{\delta j_z}{\omega _{\rm L}}\right) - \frac{\partial }{\partial z} \left(\frac{\delta j_z}{\omega _{\rm L}}\right) = - \delta v_y - \frac{\mathrm{i}}{\omega _{\rm P}}\left[ \frac{a}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a^*}{2\gamma _0}\right) - \frac{a^*}{2\gamma _0}\frac{\partial }{\partial y}\left(\frac{a}{2\gamma _0}\right) \right] \;. \end{aligned} $$](/articles/aa/full_html/2025/09/aa55899-25/aa55899-25-eq153.gif)
